Feature:
Model | HF-TGC |
Input Voltage | 12/24 VDC, |
Max Load Capacity | 2000lbs/9000N |
Stroke Length | 1 ” to 24” |
Speed at No Load | 2/3"(10mm/s) ---- 1 3/5 ”/sec (42mm/s)
|
Duty Cycle | 25% |
Operation Temperature | -26ºC~65ºC (-15ºF~150ºF) |
Limit Switch | Built-in (Factory Preset) Not movable |
IP Grade | IP54 / IP65 (dust and splash proof) |
Protection | Over Load protection by Clutch, Over temperature protection |
Optional | POT( Potentiometer), LT(limit switch) or POT-LT(potentiometer and limit switch), Hall sensor |
Specification:
MODEL | THRUST(N) | LOCK UP FORCE(N) | NO LOAD SPEED/LOAD SPEED MM/S | DUTY CYCLE(%) | MAXIMUM CURRENT(A) | |
24V | 12V | |||||
LA-C-10 | 7000 | 8000 | 10/7 | 25 | 6 | 12 |
LA-C-20 | 3500 | 4500 | 20/10 | 25 | 8 | 16 |
LA-C-40 | 1500 | 2500 | 40/30 | 25 | 12.5 | 25 |
Drawing:
Control box
Model No. Disignations
LA-C - 12 - 50 - 3 - POT
Voltage Stroke Speed (mm/s) Brackets
12VDC 50mm(2”) 10mm/sec Potentiometer
24VDC 100mm(4”) 20mm/sec
36VDC 150mm(6”) 40mm/sec
