Help CenterHydraulic Hose
US$ 50 - 250
MOQ: 400 Rolls
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
CHANGLIU
Model Number:
SAE100R1A/1AT
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
China
Brand Name
CHANGLIU
Model Number
SAE100R1A/1AT
Specifications
Hydraulic Hose Features:1) Conforms to the American standards SAE100R1A/1AT and SAE100R2A/2AT
2) Carrying medium
Hydraulic HoseFeatures:
1) Conforms to the American standards SAE100R1A/1AT and SAE100R2A/2AT
2) Carrying mediums: hydraulic oil, heavy fuel, lubricant, air, water
3) Working temperature: -40 100 degrees Celsius
4) Thickness range: 1/4 - 2"
| HangZhou ZhongCe Rubber Co.,LTD YongGu Rubber Factory | |||||||||
| EN 853 1SN | |||||||||
| SPECIFICATION | ID (mm) | OD(mm) | LAYER | working pressure | Bursting pressure | bend radius | |||
| INCH | MM | MIN | MAX | MIN | MAX | (MPA) | (MPA) | (MM) | |
| 1/4 | 6 | 6.2 | 7.0 | 13.0 | 14.1 | 1.0 | 22.5 | 90 | 100 |
| 5/16 | 8 | 7.7 | 8.5 | 14.5 | 15.7 | 1.0 | 21.5 | 85 | 115 |
| 3/8 | 10 | 9.3 | 10.1 | 16.8 | 18.1 | 1.0 | 18.0 | 72 | 130 |
| 1/2 | 12 | 12.3 | 13.5 | 19.8 | 21.4 | 1.0 | 16.0 | 64 | 180 |
| 5/8 | 16 | 15.5 | 16.7 | 23.0 | 24.5 | 1.0 | 13.0 | 52 | 200 |
| 3/4 | 19 | 18.6 | 19.8 | 27.0 | 28.5 | 1.0 | 10.5 | 42 | 240 |
| 1 | 25 | 25.0 | 26.4 | 34.9 | 36.6 | 1.0 | 8.8 | 35 | 300 |
| 1-1/4 | 31 | 31.4 | 33.0 | 42.8 | 44.8 | 1.0 | 6.3 | 25 | 420 |
| 1-1/2 | 38 | 37.7 | 39.3 | 49.4 | 52.1 | 1.0 | 5.0 | 20 | 500 |
| 2 | 51 | 50.4 | 52.0 | 63.3 | 65.5 | 1.0 | 4.0 | 16 | 630 |
| EN 853 2SN | |||||||||
| SPECIFICATION | ID (mm) | OD(mm) | LAYER | Working Pressure | Bursting Pressure | Bend Radius | |||
| INCH | MM | MIN | MAX | MIN | MAX | (MPA) | (MPA) | (MM) | |
| 1/4 | 6 | 6.2 | 7.0 | 14.5 | 15.7 | 2.0 | 40.0 | 160 | 100 |
| 5/16 | 8 | 7.7 | 8.5 | 16.1 | 17.3 | 2.0 | 35.0 | 140 | 115 |
| 3/8 | 10 | 9.3 | 10.1 | 18.5 | 19.7 | 2.0 | 33.0 | 132 | 130 |
| 1/2 | 13 | 12.3 | 13.5 | 21.5 | 23.0 | 2.0 | 27.5 | 110 | 180 |
| 5/8 | 16 | 15.5 | 16.7 | 24.6 | 26.2 | 2.0 | 25.0 | 100 | 200 |
| 3/4 | 19 | 18.6 | 19.8 | 28.6 | 30.1 | 2.0 | 21.5 | 85 | 240 |
| 1 | 25 | 25.0 | 26.4 | 37.3 | 38.9 | 2.0 | 16.5 | 65 | 300 |
| 1-1/4 | 32 | 31.4 | 33.0 | 46.4 | 49.5 | 2.0 | 12.5 | 50 | 420 |
| 1-1/2 | 38 | 37.7 | 39.3 | 54.1. | 55.9 | 2.0 | 9.0 | 36 | 500 |
| 2 | 51 | 50.4 | 52.0 | 66.1 | 68.6 | 2.0 | 8.0 | 32 | 630 |
