Heavy Machinery Hydraulic Filters Exporter PLF Hydraulic Pressure Oil Filter
Product Introduction
PLF series filter is installed on the different pressure lines of the hydraulic system;
it has high oil-passing capacity, low initial pressure loss, high dirt-holding capacity and so on,
which can meet the various requirements from the customers.
Product Characteristics
Filter basic construction
PLF series filter is composed of filter top cover and spin-on housing. Filter top cover is integral type,
according to the customer requirements, the flow direction and the mounting hole position can be custom-made.
1 Housing material
Top cover material: Ductile cast iron
Filter bowl material: Carbon steel
2 Seals
Perbunan (=NBR) (-30~+120°C); Viton=FPM(-20~+200°C)
3 Filter element
Filter medium material
High strength carbon steel skeleton
4 Optional accessories
Electric clogging indicator: CS-V
By-pass valve (Setting 6bar)
5 Type of connection (chosen according to the filter type)
Metric thread connection; Inch threaded connection; Flanged connection
About Us
1. Established in 1994 , about 21years experience .
2. Four series leading Products:
(a)Hydraulic system Cleaning&Filtration Device
(b)Complete Hydraulic Filters
(c)Hydraulic System Accessories
(d)Pump Valve Components..
3. Specialized research and development team .
4.Ninety-three thousand square meter(old plant and new plant).
5. Many stock filters .
6.The Testing Center of Xinxiang Filtration&Separation Industry Association
Our Advantage
- Manufacturer
- Competitive price can be offered
- Optimum paper folding
- Large dust holding capacity
- High efficiency.
- Breathable, Long working life.
- Good temperature resistance
- Good anti-humidity performance
- No distortion of pleats
- Environmental Friendly
- Special size available upon request
- OEM & ODM Customized is accepted
- Durable and reliable
- Economical, practical, and easy to install
- Quality as good as originals
- Sample offered upon request
P.S These are just part of our clients, in no particular order.
Test Criteria
ISO 2941 Verification of collapse/burst resistance
ISO 2942 Verification of fabrication integrity and determination of the first bubble point
ISO 2943 Verification of material compatibility with fluids
ISO 3723 Method for end load testing
ISO 3724 Verification of flow fatigue characteristics
ISO 3968 Evaluation of pressure drop versus flow characteristics
ISO 16889 Multi-Pass method for evaluating filtration performance
