High Performance XDF-MA60Q-10 Pilot Hydraulic Filter From Industrial Heavy Machinery Exporter/Fiberglass Filter Medium Material

Specifications

                                                High  Performance XDF-MA60Q-10 Pilot Hydraulic Filter from Industrial Heavy Machinery Exporter/Fiberglass Filter Medium Material

1. Product introduction

XDF-MA60Q10 filters are installed on the medium pressure line, which has high filtration accuracy, low initial pressure loss, high contamination retention capacity

and multi-purpose etc. characteristics, can meet the various requirements from the customers through assembling different accessories.

2. Product characteristics

Filter basic construction

XDF-MA60Q10 series filters consist of the cover and the spin-on housing .

1. Wide range of supply for filter, filter element and other combined filtration equipments
2. Compltely interchangeable with over 500 international brand originals
3. Very competitive price and fast delivery time

4. Imported filtration materials.

5. Making strictly in accordance with ISO, DIN, IDF and 3A standards, quality comply with GMP requirement

2.1 Housing material

Filter cover: High strength casting aluminum alloy
Filter bowl:  High-strength aluminum alloy

2.2 Seals

Perbunan (=NBR) (-30~+120°C);  Viton=FPM(-20~+200°C)

2.3 Filter element

Filter medium material

High strength carbon steel skeleton

2.4 Optional accessories

Bypass valve (setting 6 bar)

2.5 Type of connection (chosen according to the filter type)

Inch threaded connection

2.6 Symbols

3. Type selection and technical data

3.1 Order example

3.2 Technical Data

  Note: * represents filtration rating.

4. Mounting Size

5.  Product characteristic curves

The total filter assembly pressure drop is the sum of housing and element pressure drop,filter selection calculated as per the following curves.

5.1 Housing pressure drop / flow rate characteristic curves

Housing pressure drop /flow rate characteristic curves are according to ISO3968, and suitable for the mineral oil with density 0.86 kg/dm³ and kinematic viscosity 30 mm²/s.

                     Filter housing pressure drop

5.2 Differential pressure / flow characteristic curves of filter element

The characteristic curves of filter element are suitable for the mineral oil with kinematic viscosity 30 mm²/s. Differential pressure and viscosity is proportional.

                                                   Clean filter element pressure drop

  Note: If any other requriements, please consult us.

♦DFFILTRI was founded in 1995, since then we devoted ourselves to research, develop and produce many kinds of hydraulic filters, air filters, hydraulic system accessories, cleaning and filtration equipments, pump valve components. DFFILTRI is our brand, which enjoys high popularity and it has successfully achieved the position both in China and across the world.

♦DFFILTER filtration technology testing center covers a total area of 450 square meters, of which, clean room area of 200 square meters, and cleanliness is up to 100,000 levels. The centre undertakes filtration technology inspection and testing for in-house science research, production and industry service.

♦On-line particle counter of BETAB-HIAC/POYCO type (8000A/8000S) provided by HIAC/POYCO company in USA, and its supporting machine"Multi-pass test" and "single-pass test" implements ISO16889 new standard and other international standards perfectly

♦Testing center also has the developed equiment for filter performance testing, which can make the comprehensive examination for filter element/cartridge performance. These can insure that company’s filter with high capacity, long life, high reliable in full compliance with our customer's  requirement.

♦The testing centre can take 7 tests of hydraulic filter performance evaluation, they are as follows:

ISO 2941 Verification of collapse/burst resistance

ISO 2942 Verification of fabrication integrity and determination of the first bubble point

ISO 2943 Verification of material compatibility with fluids

ISO 3723 Method for end load testing

ISO 3724 Verification of flow fatigue characteristics

ISO 3968 Evaluation of pressure drop versus flow characteristics

ISO 16889 Multi-Pass method for evaluating filtration performance

Our Advantages:

1) Adopting the new industrial concept

2) Establishing world-class R&D and testing center

3) Possessing powerful technical force and R&D strength

4) Having the world's advanced production equipment

5) Producing high quality products that comply with international and national standards

6) Outstanding quality products to meet or exceed customer's expectation

7) Professional and wholehearted pre-market after-sales service

Our product mainly interchangeable with following brand

PALL, HYDAC, MAHLE, PARKER, ARGO, FILTREC, STAUFF, VICKERS, EPPENSTEINER(EPE),TAISEI KOGYO, INTERNORMEN, MANN, DONALDSON, HY-PRO, MP-FILTRI, CAT, BENZ, VOLVO, CUMMINS, ALLISON,CLARK, EPE, SCHROEDER, LIEBHERR, DOOSAN, KOBELCO, JCB, FIEETGUARD, DEUTZ, SOFIMA, DETROIT, SACMI, KUBOTA,SAKURA, WIRTGEN, FAIFILTRI, SCHAEFF, POCLAIN, LUBERFINER, DYNAPAC, PALFINGER, SOFRANCE, VALMET, CECCATO, BOBCA, MCQUDY, COMMERCIAL, TAMROCK, SAUER-DANFOSS, PERKINS, JP-HBYB, LINDE
