Tine Tillers
- 0 per Month
- As per customer requested Port
- T/T
Product Details
Condition: | New | Type: | Farm Cultivator | Power Type: | Other, Tractor driven with 3 point linkage |
Power(W): | 50-100 HP | Warranty: | 5 years | Use: | farm cultivation |
Place of Origin: | Pakistan | Brand Name: | Aeco 1007: Tine Tiller | Model Number: | 9 tines-13 Tines |
After-sales Service Provided: | Overseas service center available |
Packaging Details
20 feet container loading
40 feet container loading
polythene packing
Product Description
Specifications
Tillage implement is used after the crop has come up a few cms above the ground & for opening the land, preparing the seed beds.Tine Tillers. Aeco 1007
Ø Ideal for general cultivating, weeding, pasture renovating and preparing seed beds.
Ø The tiller is available in 4 widths: 9, 11, 13 & 15 tines. The tiller is fully mounted on the tractor by means of category I or II three point hitch pins.
Ø The spring loaded tines swing back under brake-away pressure of 163 Kg: pass over the obstruction and return to the working position without affecting the working depth of the implement.
Ø The continual flexing action of the tines shatters the soil breaking up the clods.
Ø The tiller is fitted with 51mm reversible shovels which are designed for deep penetration.
Ø A working depth up to 229 mm is possible in most soils and is simply controlled while sitting on the tractor seat.
Specifications;
- Number of tines 9 11 13
- Linkage category I 1 & II 1 & II
- Frame round steel Torsion tubes
- Overall width 2180mm 2900mm 2900mm
- Overall length 813mm 813mm 813mm
- Tine spacing 178mm 229mm 229mm
229mm 254mm 254mm
- Overall height 1.02m 1.02m 1.02m
- Cultivating width 1880mm 2590mm 2790mm
- Max. working depth 229mm 229mm 229mm
- Weight settings 209kgs 236kgs 266kgs
- Type of tines shovels spring loaded -51 mm reversible point
- Tractor capability 25-36Hp 35-55Hp 60-85Hp
Aeco Export Company established with aim of providing Best Services ,International Quality Standards, Timely Delivery and Most Competitive prices for agricultural implements, Agricultural Equipments, Agricultural Tractors new/used, Farm Machines & tools and Construction Machinery.
We export different agricultural implements like Disc Ploughs, Disc Harrows, Farm Trailers, Hyd.Tipping Trailers, Seed Drill, Rotavator/Cultivator, Jib Crane, Swinging Drawbar, Ox.Ridger, Digger, Tine Tiller, Fertilizer Broadcaster, Ridger, Front Loader, Front and Rear Blade, Thresher, Spreader, Potato digger & planter, Lawn Mover, Chaff cutter and many others.
Our Disc Harrows, Disc Ploughs & Trailers have won the African market due to best quality & competitive prices. Pictures & specifications of all products & implements are available on our website.
We export Agricultural Equipments to Different Regions of the world including Asia, Africa, Middle East, Europe, South Asia, West Africa and many others countries.
Your prompt reply & all inquiries Directly to Our Official Email ID regarding Farm Tractors Used/New & Agricultural implements, their Quantity& Port of discharge would be warm welcomed and efficiently respond by us.
Company Profile
Main Tractor Models are as under;
Massey Ferguson Tractor 240
Massey Ferguson Tractor 350+
Massey Ferguson Tractor 260
Massey Ferguson Tractor 360
Massey Ferguson Tractor 375
Massey Ferguson Tractor 385 2wd
Massey Ferguson Tractor 385 4wd
Fiat / new Holland 480 Tractors
Fiat / New Holland 640 Tractors
Fiat / New Holland 640s Tractors
AECO EXPORT COMPANY IS IN TRACTOR INDUSTRY SINCE MORE THAN 20 YEARS NOW.
we provide best quality products with fastest delivery, most competitive prices and peaceful services to our potential buyers.
we have our wide & well managed after sales services Department back up by full range of spare parts for Fiat tractors and Massey Ferguson tractors.
