Type Z2 Shaft Locking Device

Name: Type Z2 Shaft Locking Device
Brand: Suma locking device
SKU: 140279866
Availability: InStock

US$ 5 - 10 MOQ: 1 Piece

Key Specifications

Structure:

Disc

Flexible or Rigid:

Flexible

Standard or Nonstandard:

Standard

Changzhou Suma Precision Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai; Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Structure Disc

Flexible or Rigid Flexible

Standard or Nonstandard Standard

Material Steel

Brand Name Suma locking device

Place of Origin Jiangsu, China

Model Number RLK 603

Type Z2 shaft locking device

Product Description

Type Z2 keyless shaft-hub locking device /shaft locking device
Details
Model		RLK603 locking device
Material		steel
Type		locking device
Inner Diameter		14mm
Outer Diameter		38mm
Weight		0.1kg
Width		15mm
Transmissible torque		25Nm
axial force		5kN

Features

keyless shaft-hub locking device RLK 603

three-part design

high transmissible torques

Features of keyless shaft-hub locking device

1. High transmissible torques

2. Tightening of clamping screws with a torque wrench

3. Easy disassembly without jacking screws

4. Centres the hollow shaft or hub to the shaft

5.For hollow shafts or hubs with outer diameters of 14 mm up to 360 mm

specifications of keyless shaft-hub locking device

Dimensions of keyless shaft-hub locking device						Transmissible torque or axial force(Nm)		Technical Data Clamping screws				Weight	Article number
(mm)
size	D		L₁	L₂	dw*	M	F	Tightening torque M_S Nm	Number	Size	Length	kg
d		B

240	405	121	92	108	170	119 000	1400	490	12	M 20	80	62,0	4200-240301-000000
					180	138000	1530
					190	156000	1 640
260	430	133	103	120	190	161000	1 690	490	14	M 20	90	77,0	4200-260301-000000
					200	184000	1840
					210	204 000	1 940
280	460	147	114	134	210	213000	2 020	490	16	M 20	100	97,0	4200-280301-000000
					220	240000	2180
					230	269 000	2 330
300	485	155	122	142	230	274000	2380	490	18	M 20	100	116,0	4200-300301-000000
					240	296000	2460
					245	316 000	2 570
320	520	155	122	142	240	310 000	2 580	490	20	M 20	100	133,0	4200-320301-000000
					250	340000	2720
					260	373 000	2 860
340	570	169	134	156	250	381 000	3 040	490	24	M 20	110	183,0	4200-340301-000000
					260	412000	3160
					270	453 000	3 350
360	590	175	140	162	280	453 000	3 230	490	24	M 20	110	186,0	4200-360301-000000
					290	495000	3410
					295	517000	3500
