Two-part Design Axle Sleeve RLK 606

Two-part Design Axle Sleeve RLK 606 thumbnail-1
Two-part Design Axle Sleeve RLK 606 photo-1
US$ 5 - 10 MOQ: 1 Piece
Key Specifications
Get Latest Price
Structure:
Disc
Flexible or Rigid:
Flexible
Standard or Nonstandard:
Standard
Contact Supplier Request Quote Chat Now
Changzhou Suma Precision Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai; Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Structure Disc
Flexible or Rigid Flexible
Standard or Nonstandard Standard
Material Steel
Brand Name Suma
Place of Origin Jiangsu, China
Model Number RLK 608



Product Description

two-part design axle sleeve RLK 606



   two-part design axle sleeve RLK 606
Details
Model RLK606
Material steel
Type shrink discs
Inner Diameter 24mm
Outer Diameter 50mm
Weight 0.3kg
Width 22mm
Transmissible torque
 165Nm
Axial Force 17kN



Features

1. Highest transmissible torques

2. Easy, quick assembly by tightening clamping screws without a torque wrench

3. Distance-controlled assembly ensures guaranteed transmissible torques

4. Enclosed design, therefore impervious to dirt

5. True running even at high speeds

6. Centres the hollow shaft or hub to the shaft

7. For hollow shafts or hubs with outer diameters of 30 mm up to 390 mm



specifications

 two-part design axle sleeve RLK 606

Dimensions Transmissible torque or axial force(Nm) Technical Data Clamping screws Weight Article number
(mm)
size D d1 B L1  L2  C  H  dw* M F Number Size Length kg
 d
24 50 26 22 17 1 21,0 19 165 17 5 M 6 16 0,3 4200-024601-000000
20 210 21
21 240 22
30 60 32 24 19 1 23,0 24 280 23 6 M 6 16 0,3 4200-030601-000000
25 330 26
26 370 28
36 72 39 27,5 20,5 1 25,8 27 480 35 5 M 8 20 0,5 4200-036601-000000
30 630 42
33 820 49
40 80 47 29,5 20,5 22,5 1,5 27,8 30 480 32 6 M 8 20 0,6 4200-040601-000000
32 580 36
34 700 41
44 80 47 29,5 20,5 22,5 1,5 27,8 34 720 42 6 M 8 20 0,6 4200-044601-000000
35 780 44
37 920 49
50 90 53 31 24 1,5 29,3 38 1150 60 8 M 8 20 0,8 4200-050601-000000
40 1300 65
42 1520 72
55 100 58 34,5 24,5 27 1,5 32,3 42 1300 61 8 M 8 20 1,2 4200-055601-000000
45 1600 71
48 1900 79
62 110 66 34,5 24,5 27 1,5 32,3 48 1700 70 9 M 8 20 1,5 4200-062601-000000
50 1950 78
52 2160 83
68 115 72 35 24,5 27 1,5 32,3 50 1900 76 9 M 8 20 1,6 4200-068601-000000
55 2500 90
60 3150 105
75 138 79 38 28 2 34,4 55 2700 98 10 M 10 25 2,6 4200-075601-000000
60 3400 113
65 4100 126
80 141 84 38 28 2 34,4 60 3300 110 10 M 10 25 2,8 4200-080601-000000
65 4100 126
70 4950 141
90 155 94 45 31,5 35 2,5 41,4 65 5500 169 11 M 10 25 3,4 4200-090601-000000
70 6600 188
75 7900 210
100 170 104 50,5 36,5 40 2,5 46,4 70 6200 177 14 M 10 30 4,6 4200-100601-000000
75 7400 197
80 8600 215
110 185 114 57 40,5 45,5 3 53,0 80 10500 262 12 M 12 35 6,2 4200-110601-000000
85 11800 277
90 13700 304
120 197 124 61 49 3 56,5 85 12500 294 14 M 12 35 7,4 4200-120601-000000
90 14100 313
95 16000 336
125 215 134 61,5 49 3 56,5 90 14500 322 14 M 12 35 9,3 4200-125601-000000
95 16600 349
100 18800 376





Application example

Backlash free connection of a bevel spur gear to a drive shaft of a gearbox with a Shrink Disc RLK 606. The backlash free connection permits extended reversing operations.

two-part design axle sleeve RLK 606

Certifications

two-part design axle sleeve RLK 606

Packaging & Shipping

 two-part design axle sleeve RLK 606

Production and Test

two-part design axle sleeve RLK 606

FAQ

Q: Why do we choose your company?

A: We always insist quality firstl. We have our bearing factory, therefore we have advantage in quality control and price.



Q:What is the delivery time?

A: Most of the bearing we have stock. For small quantity, we will arrange delivery within 3 days.



Q: What is your payment term?

A: Our payment term include L/C, T/T, Western Union, Paypal etc.



Q: Can you send bearing samples first?

A: Yes, we can send bearing samples to check quality first.
