Help CenterRLK 133 Cone Clamping Elements With Short Axial Width With Fixed Backstop Point
Related Products
-
RLK250L Manufacturer Shaft Coupling Power Lock AssemblyUS$ 5 - 10MOQ: 1 Piece -
RLK 200 Cone Clamping Elements With Compact DesignUS$ 5 - 10MOQ: 1 Piece
-
Quick Assembly Capt Lock RLK 250US$ 5 - 10MOQ: 1 Piece
-
RLK 250 L Capt Lock Centres the Hub to the ShaftUS$ 5 - 10MOQ: 1 Piece
-
RLK 300 Power Lock for Individual Clamping ConnectionsUS$ 5 - 10MOQ: 1 Piece
| RLK 133 Cone Clamping Elements with short axial width with fixed backstop point | ||
| Details | ||
| Model | RLK133 | |
| Material | steel | |
| Type | cone clamping element | |
| Inner Diameter | 20mm | |
| Outer Diameter | 47mm | |
| Weight | 0.3kg | |
| Width | 34mm | |
| Transmissible torque |
320Nm | |
| axial force | 32kN | |
Features
1. Centres the shaft to the hub
2.Short axial width
3. No axial displacement between hub and shaft during clamping procedure due
to fixed backstop point
4.For shaft diameters between 20 mm and 200 mm
specifications
Application example
Backlash free connection of a timing belt pulley to the drive shaft with a Cone Clamping Element
RLK 133. Due to the fixed backstop point, the timing belt pulley is not displaced axially during
clamping. The Cone Clamping Element also centres the timing belt pulley to the shaft. The
compact Cone Clamping Element is a costefficient solution especially for applications with
low space requirements.
