Main techinical data&features:
| Tiller | Model | QLG500 |
| Body Size(mm) | 1390*800*1070 | |
| Tilling Scope(mm) | 750-1350 | |
| Tilling Depth(mm) | 150-350 | |
| Gear Shifting | 0,1,2/-1,0,1/0,1,2,-1 | |
| Transmission Type | Belt | |
| Transmission Oil Capacity(L) | 1.1 | |
| Engine | Engine Model | ZX186F(DIESEL) |
| Max. Power Output hp/rpm | 9/3600 | |
| Packing | Dimension(mm) | 1030*570*880 |
| 20FT(set) | 54 | |
| N.W./G.W.(kg) | 150/160 | |
| Note | with wheels(500-12) and mud fender |
Features:
The machine is multifunctional when it is connectd with the relevant tools,
the machine is widely used in agriculture production, it can covers all kinds
of operations,such as plowing,deep scarification,soilcrushing, ditch digging,
bedding,film laying,weeding, hilling up,pesticide spreading, harvesting etc.
Tips:
a.When transporting the hoeing machine, turn the fuel valve OFF and keep the tiller level to prevent fuel spillage. Fuel vapor or spilled fuel may be ignited.
b.Be sure the clutch is disengaged and the shift lever is in the neutral position to prevent sudden uncontrolled movement when the engine starts. The clutch is engaged by pulling in the clutch lever and disengaged by releasing the lever.
c.Do not allow the starter grip to snap back against the engine. Return it gently to prevent damage to the starter.
d.Allowing any one to operate this tiller without proper instruction may result in injury.
e.To prevent damage, check the tiller for any signs of damage or other faults each time the tiller is used after it has been operated.
