Specifications
1. API standard.2. ISO certificate.
3. Register with Sinopec.
4. Technical service.
5. Professional service for export.
Certificate of our company
Pictures of our company
Specifications:
Series TFZ 35-70A casing head
Based on all kinds of drilling and oil-production casing head used in the oilfields at home and abroad and Series TFZ35-70A casing head, considering of the actuarial conditions of drilling process flow, is a new patent product (Patent No.01217781.4), which gathers all of the advantages of casing heads, simples installation process and furthers to raise the safety and reliability.Main technology parameters
Casing procedure: 20" ,13 3/8",9 5/8",7" or 5 1/2";
Connection:
Of the top: 13 3/8"x5000psi (10000PSI) flange with gasket ring BX 160 (BX159);
Of the bottom: 13 3/8" CSG casing thread;
Flange of side outlet: 35 & 65 R27 (70& 65 BX153);
Supporting load:5000KN;
Interchangeable hanger: 4", 41/2", 51/2", 7" & 95/8
Working pressure: 35MPa (70MPa)
Suitable depth of well: 5000~7000m
Working temp: PU level;
Working medium: Oil, gas and mud;
Vertical bore minimum 316mm
Rated material class: DD
