Home > Products > wellhead Tools > Oilfield equipment Rotary Slips SDS-Short Rotary Slips manufacturer
Oilfield equipment Rotary Slips SDS-Short Rotary Slips manufacturer
USD $1 - $500
/ Piece
1 Piece(Min.Order)
- 10000 Piece / Pieces per Month
- Tianjin Qingdao
- T/T
You May Like
- API-7-1 Standard single cone drill bit
- 6 7 11 12 degree Diameter 32mm Taper Knock off drill bit
- Oilfield cementing tool cement head for drilling rig
- Oilfield Tools API 5CT double dual single plug cementing Head
- API 7K Single Pulg/Double Plug Cement Head For Cement
- Oilfield double/single plug casing cement head for cementing equipment
Product Details
Place of Origin: | Shandong, China | Brand Name: | Slruite | Model Number: | RUITE1 |
Type: | Slip | Machine Type: | Drilling Tool | Certification: | API |
Material: | Stainless Steel | Use: | Well Drilling |
Product Description
Certificate of our company
Pictures of our company
Pictures
Specifications:
SDS-Short Rotary Slips
Slip Body size (inch) | 3 1/2 | 4 1/2 | ||||
Oilman Code | 4010101 | 4010102 | ||||
API pipe size (OD inch) | 2 3/8 | 2 7/8 | 3 1/2 | 3 1/2 | 4 | 4 1/2 |
Parts No. slips c/w inserts | 3901 | 3903 | 3905 | 3907 | 3909 | 3911 |
Weight. Slips c/w inserts lb (kg) | 117 (53) | 111 (50) | 107 (48.5) | 143 (65) | 136 (62) | 127 (58) |
Qty of inserts | 24 | 24 | 24 | 36 | 36 | 36 |
Weight of inserts lb (kg) | 21 (9.5) | 16 (7) | 10 (4.5) | 32 (14.5) | 25 (11) | 16 (7) |
SDML-Medium Rotary Slips
Slips Body Size (inch) | 3 1/2 | 4 1/2 | 5 | 5 1/2 | ||||||||
Oilman Code | 4010103 | 4010104 | 4010105 | 4010106 | ||||||||
API pipe size (OD inch) | 2 3/8 | 2 7/8 | 3 1/2 | 3 1/2 | 4 | 4 1/2 | 4 | 4 1/2 | 5 | 4 1/2 | 5 | 5 1/2 |
P/N Slips c/w inserts | 15524 | 15523 | 15522 | 15563 | 15564 | 15565 | 15567 | 15568 | 15569 | 15571 | 15572 | 15573 |
Weight slips c/w inserts lb (kg) | 193 (87.5) | 188 (85) | 180 (81.5) | 207 (94) | 199 (90) | 188 (81.5) | 204 (92.5) | 196 (89) | 185 (84) | 200 (91) | 185 (84) | 181 (82) |
Qty of inserts | 30 | 30 | 30 | 45 | 45 | 45 | 45 | 45 | 45 | 45 | 45 | 45 |
Weight of inserts lb (kg) | 26 (12) | 22 (9.5) | 13 (6) | 39 (17.5) | 31 (14) | 20 (9) | 39 (17.5) | 31 (14) | 20 (9) | 39 (17.5) | 31 (14) | 20 (9) |
SDXL-Extra Long Rotary Slips SDXL & SDL Inserts
Slips Body Size (inch) | 4 1/2 | 5 | 5 1/2 | ||||||
Oilman Code | 4010107 | 4010108 | 4010109 | ||||||
API PIpe OD (Inch) | 3 1/2 | 4 | 4 1/2 | 4 | 4 1/2 | 5 | 4 1/2 | 5 | 5 1/2 |
P/N slips c/winserts | 15515 | 15514 | 15513 | 15518 | 15517 | 15516 | 15521 | 15520 | 15519 |
Weight slips c/w inserts lb (kg) | 229 (104) | 219 (99) | 205(93) | 237(105) | 227(103) | 213(96.5) | 234(106) | 224(101.5) | 210(95) |
Qty of inserts | 54 | 54 | 54 | 54 | 54 | 54 | 54 | 54 | 54 |
weight of inserts lb (kg) | 47(21) | 37(17) | 23(10.5) | 47(21) | 37(17) | 23(10.5) | 47(21) | 37(17) | 23(10.5) |
