Drilling Rig Solid Control Equipment 3NB F Series Triplex Mud Pump Parts

Drilling Rig Solid Control Equipment 3NB F Series Triplex Mud Pump Parts thumbnail-1
Drilling Rig Solid Control Equipment 3NB F Series Triplex Mud Pump Parts photo-1
US$ 2,000 - 20,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
Slruite
Condition:
New
Contact Supplier Request Quote Chat Now
Shengli Oilfield Ruite Machinery Manufacturing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name Slruite
Condition New
After-sales Service Provided Overseas third-party support available

Specifications

1. API standard.
2. ISO certificate.
3. Register with Sinopec.
4. Technical service.
5. Professional service for export.

On the basis of the imported technology, the Chinese manufacturers designed and manufactured F-1300, F-1600, F-1600L, F-1600HL, F-2200, F-2200HL mud pumps, which conform to API 7K specifications.






Model 		  F-500 F-800 F-1000 F-1300
Type   Triplex single acting piston pumps
Max liner × Stroke length mm 170×191 170×229 170×254 180×305
in 63/4×71/2 63/4×9 63/4×10 7×12
Strokes rating spm 165 150 140 120
Rated power kW 373 597 746 970
HP 500 800 1, 000 1, 300
Gear ratio   4.286:1 4.185:1 4.207:1 4.206:1
Suction manifold mm 203.2 254 304.8
in 8 Flgd 10 Flgd 12 Flgd
Discharge port mm 102 127
in 4 Flgd 5, 000 Psi 5 Flgd 5, 000 Psi
OD of pinion shaft mm 139.7 177.8 196.85 215.9
in 51/2 7 73/4 81/2
Key mm 31.75×31.75 44.45×44.45 50.8×50.8
in 11/4×11/4 13/4×13/4 2×2
Valve pots   Valve-over-Valve
  API 5# API 6# API 6# API 7#
Weight kg 9, 770 14, 500 18, 790 24, 572
lbs 21, 540 31, 970 41, 420 54, 170







Model   F-1600/1600 L F-2200 F-1600 HL F-2200 HL
Type   Triplex single Acting piston Triplex single acting plunger
Max liner × stroke length mm 180×305 230×356 190×305 230×356
in 7×12 9×14 7-1/2×12 9×14
Strokes rating spm 120 105 120 105
Rated power kW 1, 194 1, 640 1, 194 1, 640
HP 1, 600 2, 200 1, 600 2, 200
Gear ratio   4.206:1 3.512:1 4.206:1 3.512:1
Suction manifold mm 304.8
in 12 Flanged
Discharge port mm 127
in 5 Flanged, 5, 000 Psi
OD of pinion shaft mm 215.9 254 215.9 254
in 81/2 10 81/2 10
Key mm 50.8×50.8 63.5×44.45 50.8×50.8 63.5×44.45
in 2×2 2-1/2×13/4 2×2 2-1/2×13/4
Valve pots   Valve-over-Valve L type
  API 7# API 8# API 7# API 8#
Weight kg 24, 791 29, 400 38, 460 43, 080
lbs 54, 660 64, 820 84, 790 94, 980







Certificates of our company





Drilling rig solid control equipment 3NB F Series triplex Mud Pump parts







Pictures of our company



Drilling rig solid control equipment 3NB F Series triplex Mud Pump parts







Our workshop









Drilling rig solid control equipment 3NB F Series triplex Mud Pump parts







Drilling rig solid control equipment 3NB F Series triplex Mud Pump parts
