Specifications
small wheel loader ZL08 single cylinder engine compact structure farm & construction usage lowest pricesmall wheel loader ZL08 single cylinder engine compact structure farm & construction usage lowest price
0.6-1.5 tons small wheel loaderadpots the static hydraulic transmission, four-wheel driving, expand hoof brake, articulated frame, load sensing fully hydraulic steering and the oscillating feature of rear axle, with them, this series wheel loader realize the flexile operation as well as stable working. It is mainly used for loose materials loading and transporting job on construction yards, goods yards, roads and mines.
1. The longest guarantee promise: 2 year
2. Delivery time: within 15 workdays
3. Sample tractor can order from us.
1. Most of easy worn parts such as oil filter, fuel filter, air filter, inner tyre etc. are delivered for 2 year, for every wheel loader.
1. Air Conditioner
2. Joystick
3. Quick Hitch
4. Fork
5. Rops Cabin
Lift fork, wood grasper, digger, snow pusher, excavator, snow transbox, grass grasper ... ...
MODEL |
ZL06 |
ZL08 |
ZL10 |
ZL12 |
ZL15 |
Weight (kg) |
1650 |
2000 |
2400 |
3800 |
4200 |
Rated load (kg) |
600 |
800 |
1000 |
1200 |
1500 |
Rated power (kw) |
16.18 |
17 |
24 |
38 |
45 |
bucket cubage (m3) |
0.3 |
0.4 |
0.5 |
0.6 |
0.6 |
Max. running speed (km/h) |
20 |
20 |
20 |
30 |
30 |
Max. climbing gradient ( °) |
20 |
20 |
20 |
25 |
25 |
Max. Loading height (mm) |
≥ 2200 |
≥2400 |
≥2400 |
≥2800 |
≥2900 |
Max. unloading distance (mm) |
≥900 |
≥900 |
≥900 |
≥950 |
≥950 |
Shake lifting time ≤ (s) |
6 |
6 |
6 |
7 |
7 |
Unloading time (sand) (s) |
3-5 |
3-5 |
3-5 |
3.5-6 |
3.5-6 |
Digging power ≥ (kn) |
22 |
22 |
22 |
24.4 |
24.4 |
Tread (mm) |
1150 |
1160 |
1160 |
1460 |
1460 |
Wheelbase (mm) |
1600 |
1620 |
1620 |
1800 |
1800 |
Engine model |
1115 |
1120 |
2105/480 |
490 |
4100 |
Min. turning radius (mm) |
3000 |
3000 |
3000 |
3200 |
3200 |
Steering type |
Power steering |
||||
Overall size (mm) |
4460x1300x2000 |
4490x1400x2100 |
4590x1520x2560 |
5200x1690x2560 |
|
Driving type |
Rear 2 wheeled or full 4 wheeled |
Full hydraulic |
|||
