Specifications
mower1.2-1.8m
MODELS |
FM-120 |
FM-150 |
FM -180 |
CUTTING WIDTH(INCHES) |
120cm(48") |
150cm(60") |
180cm(72") |
DIMENSIONS |
1330x860x480mm |
1640x995x480mm |
1930x1180x480mm |
CUTTING HEIGHT(INCHES) |
25-100mm |
25-100mm |
25-100mm |
WORKING EFFICIENCY |
4000-10000m2 |
4500-12000m2 |
5000-15000m2 |
TRACTOR POWER |
15-30hp |
25-50hp |
40-70hp |
WHEELS SIZES |
Solid Rubber Tires with ball bearings 210 x 80 mm |
||
No.OF TRANSMISSION SHAFTS |
4 |
4 |
4 |
No.OF BLADES |
3 |
3 |
3 |
BLADE MATERIAL |
Spring Steel |
||
BLADE SIZES |
422x60x6mm |
522x60x6mm |
623x60x8mm |
BLADE SPEED |
3375rpm |
2700rpm 4425m/min |
2250rpm |
3-POINT CATEGORY HITCH |
I |
I or II |
I or II |
PTO.POWER REQUIRED |
10~16kw 13~21hp |
12~24kw 16~33hp |
25~32kw |
OPTIMUM P.T.O. |
540rpm |
540rpm |
540rpm |
P.T.O SPINE |
6x6x900mm |
6x6x900mm |
6x6x900mm |
MACHINE WEIGHT |
195kg |
215 kg |
265kg |
OIL TYPE |
EP SAE 80W 90 |
||
OIL AMOUNT |
0.9 L (Gal. 0.20) |
||
DISCHARGE |
R-rear; S-side(left); RC-rear discharge with chain. |
||
