Mazda diesel engines parts T3500 piston(piston ring, cylinder liner also)
A: T3500 engine piston, piston ring, cylinder liner details
Application for Mazda engines:
| C/F-No | E-Model | OEM No | Piston Size | OEM No | Ring Size | OEM No | Liner Size | ||
| CF-MA-08 | T3500/SL |
SL07-23-200 SL07-23-200B SL01-23-200A |
Dia: | 100 |
SL07-23-206 SL07-23-206A SJT20-046 SL01-23-206 SL01-23-206A |
2.5 2 4.5 |
SL01-23-311 SL01-23-312 K410-10-311B SL07-23-051 SL01-23-313 |
A: | 100 |
| GL: | 105 | B: | 103.5 | ||||||
| KH: | 58 | C: | 193.5 | ||||||
| Pin Dia: | 34 | W: | 0.79 | ||||||
| Length: | 82 | phosphiate | |||||||
| Remark | alfin | ||||||||
| C/F-No | E-Model | OEM No | Piston Size | OEM No | Ring Size | OEM No | Liner Size | ||
| CF-MA-09 | TF4000 |
TF01-11-SAO TF20-11-SAO 8P05F01-P |
Dia: | 105.5 |
TF01-11-SCO SDT20-057 8R05F01 TF0111SCO R30505 |
2.5K 2 4.5 |
TFY0-10-311A TFY0-10-311B 8P05F01-P TFY0-10-311 |
A: | 105.5 |
| GL: | 108.3 | B: | 109 | ||||||
| KH: | 61.4 | C: | 200 | ||||||
| Pin Dia: | 35 | ||||||||
| Length: | 87 | ||||||||
| Remark | alfin | ||||||||
| reinforced and oil gallery | |||||||||
B: For Mazda engine details:
we can offer the following engines as well:
1. FB
2. NA
3. F8
4. R2
5. FE
6. S2
7. T3500/SL
8. TF4000
C: and also, for Japanese engines, we have the following brand:
Hino, Mazda, Nissan, Toyota, Isuzu, Mitsubishi ......
D: Production details:
(A). Our piston details:
1). Piston Material : ZL109 Aluminium Alloy , Alloy cast iron.
2). Piston Type :1 Steel-insert piston , 2 ALFIN piston , 3 Cast Iron piston , 4 Cooling channel piston , 5 One piece casting piston , 6 Compages piston , 7 Forged piston
3). Piston Feature : Satin Anodised Aluminium ,phosphating , Alfin ,Double Alfin , No Alfin , Graphite , Oil cooling channel , Sn(tin) plated , Steel Piece , Top Oxidization ,
Skirt Graphite Printed , Three or Four Ring Grooves ,Ceramic Spraying4. We can offer you The 1 Steel-insert piston , 2 ALFIN piston , 3 Cast Iron piston ,
4 Cooling channel piston , 5 One piece casting piston , 6 Compages piston , 7 Forged piston piston, 8 Two pieces piston/Double piston
(B). Our Piston ring details:
1). Piston ring Material : Cast iron , Alloy , Steel
2). Piston ring Feature : 1.Chrome-plating ,2.Line-honing ,3.nitridation , 4.phosphating , 5.Molybdenum plated(Moly-inlaid) ,6.Nitrided ,7.Oxidized,8.Nano,
9.Zirconium-plating ,10.Sandblasted ,11.Special honing, 12.Titanium-plating, 13.Rail With Teflon
(C). Our Cylinder Liner details:
1). Cylinder liner/ sleeves Material: Boron-containing Alloy Cast Iron
2). Cylinder liner/ sleeves Treatment: laser quenching, high-frequency quenching
3). Cylinder liner/ sleeves Feature: Dry, Wet & Air Cooled Blocks
(D). Our Engine bearing details:
1.Material
1)Steel backing material
2)Alloy layer material-----a:Bronze-based b:Aluminium-based
2..Main Surface treatment--Tinning
1). Prevent oxidation corrosion
2). Cover Steel back and bearing between the poor fit of some shape defects
3). Beautifying
