Help CenterCylinder Liner
Related Products
Specifications
cylinder liner1. Steel cylinder liner
2. Cast iron cylinder liner
3. Cylinder sleeve
Cylinder liner for Isuzu 6BD1 engine
CNFLAP AUTO PARTS: Piston, Piston ring, Cylinder liner, engine bearing, engine gaskets, engine valves.
A. Cylinder liner/sleeves details:
1. Cylinder liner/ sleeves Material: Boron-containing Alloy Cast Iron
2. Cylinder liner/ sleeves Treatment: laser quenching, high-frequency quenching
3. Cylinder liner/ sleeves Feature: Dry, Wet & Air Cooled Blocks
4. Certification:TS16949, ISO9000, ISO 9002
5. Our cylindee liner MOQ is 1000pcs.
B. REMARK:
1).Dry, Wet & Air Cooled Blocks suitable for more than 1450 types of Series of various models & Make..
2).Good quality, Good packing, Good finish
3)Competitive price, Guarantee 100000km
4).Secure service & Packing Details: Meet your requirement
5).Piston, Piston ring, Cylinder liner, Auto AND Diesel parts engine parts, Liner kits, Spare parts
6).We can develop the new items according to the sample or product draft especially for you.
7).We sell piston , Piston ring and cylinder liner's Diameter from 80 mm to 160 mm
8).Main products: PISTON / PISTON RING / CYLINDER LINER
9).Product Characteristics: Germany and Japanese advanced technology , Wear proof , High temperature resistant
C .WE can supply piston , piston ring , liner used in car , truck , tractor , Combat Engineer AS BELOW:
(1) WEST EUROPE VEHICLE TYPE: bedford, benz, Peugeot, daf, fiat, iveco, deutz, land rover, liebherr, lombardini, man, mwm, opel, perkins, renault/rvi, scania, vw
(2)EAST EUROPE VEHICLE TYPE: belarus, compressor, kamaz, mtz, steyr, howo, utb, zetor
(3)AMERICAN VEHICLE tYPE: cat, caterpillar, case international, cummins, international, ford, lister, volvo
(4)JAPANESE VEHICLE TYPE: daihatsu, Nissan, hino, komatsu, mazda, mitsubishi, Suzuki, toyota, yanmar
(5)KOREAN VEHICLE TYPE: Daewoo, hyundai, isuzu, kia
Isuzu cylinder liner model details with OEM
| C190 | 9-11261224-1 | 86 | DRY |
| C240 | 9-11261230-1 | 86 | DRY |
| C223 | 5-11261-015-2 | 88 | DRY |
| 4JA1 | 8-94462-130-0 | 93 | DRY |
| 4JB1 | 8-94247-861-2 | 93 | DRY |
| 6BD1/T | 1-11261-118-0 | 102 | DRY |
| 6BG1 | 1-11261-119-0 | 105 | DRY |
| 4BE1 | 5-11261-016-2 | 105 | DRY |
| DA120 | 100x118.8x220 | DRY | |
| 6HE1T | 8-49390-530-D | 110x113x210 | DRY |
| 4HF1 | 8-97176727-0 | 112× 115×180 | DRY |
| 4HF1 | 8-94389-276-3 | 112.07× 115×180 | DRY |
| 4HG1 | 8-97351-558-0 | 115× 118×180 | DRY |
| 10PA1 | 1-11261-063-0-1 | 115x142x219 | DRY |
| 10PC1T | 1-11261-076-0 | 119x143.6x219 | DRY |
| 10PC1 | 1-11561-111-0 | 119x143.5x219.5 | DRY |
| 10PD1 | 1-11261-161-1-0 | 119x143.5x234 | DRY |
| 6SD1 | 1-11261-106-2 | 120x123x239 | DRY |
| 6SD1 | 1-11261-106-2 | 120x123x239 | DRY |
| 10PE1 | 127x130.5x233.2 | DRY | |
| 6RA1 | 1-11261-105-1 | 135× 141×264 | DRY |
| 1-11261-160-0 |
If you are interested in them, plz let me know!
