H100 Piston Ring

Specifications

H100 piston ring:
OEM NO. ENGINE MODEL CYL/SET DIA
k-1 87 4 104
23040-42200 H100/3mm 4 91.1
23040-4200 4D55-56/4mm

H100 piston ring



A: D4BH engine piston ring:

   Application for Hyundai engines:

   Piston details:
   Dia: 91.1
   GL:  81.7
   KH:  41.5
   Pin Dia: 29
   Length:  75
   Remarks: Alfin, oil gallery



C/F-No	E-Model	OEM No	Piston Size		OEM No	Ring Size	OEM No	Liner Size
CF-HY-07	D4BH	23410-42411	Dia:	91.1	2304042000	2.5      2       4		A:
			GL:	81.7				B:
			KH:	41.5				C:
			Pin Dia:	29
			Length:	75
			oil-gallery



B: Hyundai engine details:

   we can offer the following engines as well:
   1. SANTRO ATOS
   2. ACCENT 1.3
   3. ELANTRED
   4. 4D56
   5. D4BB/H100
   6. D4BA
   7. D4BH
   8. K2700 SS
   9. D4AE/4D31T
   10. D4AF
   11. D4DB/4D34TC1
   12. D4BX


C: and also, for Korean truck engines, we have the following brand:

   Hyundai,Kia, Daewoo  ......



D: Production details:

   1. materials for piston:
   2. materials for the piston pin:

   3. produced by the OEM technical drawings or the sample



E: Gurantee for the piston:

   1. we strictly adhere to the GB1148-82,JB3931-85 and JB3932-85 Criterion

   2. send sample for check before delivery

F: Packing details:
   1. we can design the packing by your requirements but with bigger quantity

   2. if need wooden pallets, the customer needs to pay for the wooden pallet charges

   3. if no requirements,we offer the Corrugated Carton and vellum paper





More pic for your ref.
