micro piston pump

netural packing or meet your requirement based on your large quantity

Specifications

1.FL921 piston
2.100*110*222.8
3.air-cooled cylinder liner
4.OE:02231924
5. have passed TS16949 and ISO9000

micro piston pump



A: product deatils



C/F-No	E-Model	OEM No	Piston Size		OEM No	Ring Size	OEM No	Liner Size
CF-DZ-03	FL921	91395600	Dia:	100	800012512000   09933N0	3T      2.5    2.5    5	099WR08 1490008000 89005110 89005210      OE: 02231924 04157763 04157756 04158559    02231975  SJ351065V1	A:	100
			GL:	118				B:	110
			KH:	72				C:	222.6
			Pin Dia:	35				air-cooling
			Length:	80





B: Piston knowledge

   Air-cooled cylinder liner:
in accorance with the instructions from the engine manufactures, cast iron cylinders or light alloy cylinders are used. Light alloy cylinders are separeated into several groups due to the small installation clearance in the standard cylinder dimensions.




C: For Cylinder liner:
1) Characteristics :Germany etc.advanced technique &wear proof &high temperature resistant etc.
2) Materical:boron alloy,boron-coper alloy casting iron&Mixing with chrome,molybdenum ,nickel etc.
3) Different Treatment Phosphated,Nitrided,Chrome plated
4) Develop the new items according to thg sample or product
5) Products:cylinder liner/liner kit /piston /piston ring /


D: Shippment method



E: Packing



 F: introduction



Production equipments:
  1: Single-piece Oval Piston Ring Bland Casting production Line Using High pressure MoldingMachine imported from GOETZE AG ,.Germany,GOETZE AG ,.Germany Production Line and GOETZE Automatic Molding Machine
  2: Introduced INDUCTOTHERM furnace from USA
  3: Full Automatic Piston Ring Grinding Machine imported from KATAOKA Co.,LTD,Japan
  4: Keystone Grinding Machine imported from Goetze AG.,LTD,Germany Improved quality by adopting computer electrical control, automatic tooling positioning and feeding technology
  5: Piston Ring Processing Machine imported from KATAOKA Co.,LTD,Japan
  6: We have advanced foundry,heat treatment,surface treatment,processing equipment,Inspection and test equipment craft ,development ability in piston ring manufacture



G: Cnflap company

     we are the manufacture for the piston kits since 1995,we have started to produce the piston. At present,we can produce the alfin piston, oil-gallery piston, steel pieces piston,and cooper pin bush piston for our customer. And also we can develop the new items for our customer.





Piston:
Alfin materials: Wear Ring of High Ni Austenitic Cast Iron
Piston materials: ZL109 Aluminum and ZL108 Aluminum
Piston pin materials: 40CrMo and 20CrMo




Piston ring:
Ductile cast iron with Chrome-coated, Spray-Molybdenum, Gas-Nitrading, Phophate, Special-Grinding, Oxidation etc.




Cylinder liner:
Materials: Boron-Containing Alloy Cast Iron Surface Treatments: Alramenting, Chrome-faced, Surfeced colored, Inside Hole Laser Hardening







If you would like to know more details , pls kindly call me or send me email
