98.5mm Size Liner

Specifications

98.5mm size liner

We can supply various kind of perkins engine parts cylinder liner .

PERKINS LINER

Cnflap NO. Engine Reference NO. Size (Inside Bore*Outside Bore *Total Length) Note Weight

CF-PKS-001-03 3.152 31358384 90.7*216.1 SEMI

CF-PKS-002-03 3.152 31358345 91.5*93.6*216

CF-PKS-003-03 3.152 31358323 91.49*216.1 SEMI

CF-PKS-004-03 4.236 6.354 31358403 745-340-M1 97.61*227.28

CF-PKS-005-03 4.236 6.354 31358399 97.61*227.28

CF-PKS-006-03 4.236 6.354 31358393 744-131-M1 97.61*227.28 SEMI

CF-PKS-007-03 4.236 6.354 3135*031 97.61*226.44 SEMI

CF-PKS-008-03 4.236 6.354 31358398 98.501*227.28

CF-PKS-009-03 4.236 6.354 31358396 745-245-M1 98.247*227.28

CF-PKS-010-03 4.236 6.354 31358397 745-246-M1 98.501*227.28

CF-PKS-011-03 4.236 3135*035 98.501*226.44

CF-PKS-012-03 4.236 6.354 31358394 744-948-M1 98.501*227.28

CF-PKS-013-03 4.236 6.354 31358395 744-132-M1 98.247*227.28

CF-PKS-014-03 4.236 6.354 3135*032 98.501*226.44

CF-PKS-015-03 T4.236 4.238 98.48*228.8 SEMI

CF-PKS-016-03 T4.40 T6.60 3135*063 99.162*227.447 SEMI

CF-PKS-017-03 T4.40 T6.60 3135*041 748-215-M1 99.162*226.44

CF-PKS-018-03 4.40 6.60 3135*044 99.7*226.44

CF-PKS-019-03 T4.40 T6.60 3135*061 99.825*227.477

CF-PKS-020-03 T4.40 T6.60 3135*062 100.038*227.447

CF-PKS-021-03 T4.40 T6.60 T4.401 T6.601 3135*065 100.038*227.477

CF-PKS-022-03 T4.40 T6.60 3135*042 748-216-M1 100.038*226.44

CF-PKS-023-03 4.248 3135*033 748-760-M1 100.1*226.44

CF-PKS-024-03 4.40 6.60 3135*045 100.038*226.44

CF-PKS-025-03 4.248 6.335 6.372 31358346 100.092*227.28

CF-PKS-026-03 31358343 100.1*223.9 SEMI

CF-PKS-027-03 4.248 6.335 6.372 31358352 742-456-M1 101.092*227.28

CF-PKS-028-03 4.248 3135*034 748-761-M1 101.092*226.44

CF-PKS-029-03 A4.318 31358533 745-990-MI 113.31*230.78

CF-PKS-030-03 A4.318 31358534 745-991-M2 114.389*230.43

CF-PKS-031-03 V8.640 3135*021 746-675-MI 116.8*225.53

CF-PKS-032-03 V8.640 31358531 745-543-M1 116.71*226.16

CF-PKS-033-03 V8.640 3135*022 746-676-MI 117.64*225.53

CF-PKS-034-03 V8.640 31358532 745-544-M1 117.627*226.16

Dia from 90.7mm 91.49mm 97.61mm  98.247mm  98.48mm  98.5mm 99.162.mm  99.7mm

99.825mm 100.038mm  100.092mm  100.1mm  101.092  113.31mm  114.389mm  116.71mm  116.8mm  117.627mm  117.64mm

Model No.: V8.640  A4.318 4.248  T4.40 T6.60  4.40/6.60  4.236  4.40/6.600  4.236  6.354  6.335  6.372  V8.640 4.248 6.335  6.372  T4.401  T6.601   3.152  4.236  6.354  A4.318  T4.236  4.238   31315X021/746-675-M1  3135X022  746676-M1  31358533  745-990-M1

3135X033/748-760-M1  3135X034/748-761-M1  3135X041/748-215-M1  3135X042/748-216-M1  3535X044/  3135X035  3135X04  31358403 745-340-M1  31358398  31358399   31358396  745-245-M1  3135397  745-246-M1  31358346  31358531  745-543-M1  31358532  745-544-M1   3135X0641  3135X065  34358345  3135323  31358394  744-948-M1  31358393-744-131-M1  31358395744-132-M1 3135X031  3135X032  3135X063 3135X062  31358534/745-991-M2 31358343

Remark:
1)For European& American, Korean & Japanese and Russian etc. Engines

2)Good quality ,good packing,good finish

3)Competitive price ,guarantee 100000km

4)Secure service

5Packing Details:Meet your requirement

6)We can develop new items for you especially
