6.0hp gasoline Gear-drive Rear Tine Rototiller
USD $1 - $450
/ Unit
5 Units(Min.Order)
- 150 Unit / Units per Month
- chongqing
- T/T
You May Like
Product Details
| Condition | New | Type | Farm Cultivator | |
| Power Type | Gasoline | Certification | CE | |
| Use | tilling the land | Place of Origin | Chongqing, China | |
| Brand Name | WINYOU | Model Number | 400 |
Product Description
Specifications
Heavy Duty Gear Drive TrannyEasy CONTROL YOUR DEPTH
WORKS IN ALL TYPES OF SOIL
STORNG,LONG-LASTING COMPONENTS...
1.data & standard
diesel cultivator,gasoline/diesel power tiller parameters
| Model No. | WY360 | WY400 | WY500 | WY900 | WY1000C | WY1100C | |
| Tilling | |||||||
| Tilling scope (mm) | 360 | 550 | 500-1000 | 800-1200 | 800-1000 | 800-1100 | |
| Tilling depth (mm) | 200 | 150-250 | 150-250 | 150-300 | 150-300 | 150-300 | |
| Transmission type | Belt | Gear | Belt | Belt | Gear | Gear | |
| Transmission oil (L) | 0.2L | 0.6 | 0.95L | 1.1L | 1.0L | 1.1L | |
| Transmission Material | Iron plate | aluminum | aluminum | Cast iron | Aluminum + Cast iron | ||
| Gear Shifting | 0,1 | 0,1 | 0,1,2,-1 | 0,1,2,-1 | 0,1,2,3,-1 | 0,1,2,-1 | |
| Tilling blade | 4-2 blades | 3-4 blade | 3-4 blade | 3-4 blade | 3-4 blade | 4-4 blade | |
| Gasoline Engine | |||||||
| Engine model | WY1P70FV | WY1P70FV | WY170F | ||||
| Engine Type | Vertical shaft ,4 stroke, single cylinder,air-cooled | Horizontal shaft ,4 stroke, single cylinder,air-cooled | |||||
| Displacement (cc) | 173cc | 173 | 212 | 212 | 212 | 212 | |
| Bore×Stroke(mm) | 70x45 | 70x45 | 70x55 | 70x55 | 70x55 | 70x55 | |
| Max power output(HP/rpm) | 4.3kw(6.0HP)/3600 | 4.3kw(6.0HP)/3600 | 7.0/3600 | 7.0/3600 | 7.0/3600 | 7.0/3600 | |
| Max torque(N•m/rpm) | 9.0N.m/3600rpm | 9.0N.m/3600rpm | 11.5/3000 | 11.5/3000 | 11.5/3000 | 11.5/3000 | |
| Starting type | Manual start | Manual start/electric start | |||||
| Fuel tank capacity (L) | 1.7 | 1.7 | 3.6 | 6 | 6 | 6 | |
| Oil capacity (L) | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 | |
| Packing Details | |||||||
| Carton Dimension(mm) | 700x390x700 | 700x390x700 | 680x460x710 | 880x460x840 | 1060x560x895 | 1060x560x895 | |
| N/G•W(kg) | 34/36 | 34/36 | 60/74 | 70/85 | 105/120 | 110/125 | |
6.0hp vertical shaft petrol engine 1P70
Tilling Blades and Plows /Plough:
Rubber wheels/Iron Wheels:
Standard Packing:
mini gasoline rotary tiller machine/ diesel rotary tiller machine/diesel farm rotocultivator package
Our other products : gasoline engine,diesel engine,gasoline water pumps,diesel water pumps ,gasoline tillers,diesel tillers,gasoline generators ,grass cutters :
