Hot selling high quality semi trailer axle with round beam 16T
Specification of BPW type trailer axles
| Model |
Capacity (kg) |
Cam Brake (mm) |
Track TR (mm) |
Spring Seat installation (MM) |
Axle Beam (mm) |
Center distance of Chamber (mm) |
Total length (mm) |
Recommended |
Weight (kg) |
Wheel PCD (mm) |
Wheel H (mm) |
| BPW-021 | 12.000 | S420*180 | 1840 | 980 | S150 | 422 | 2155 | 7.50V-20 | 370 | 335 | 281 |
| BPW-022 | 14.000 | S420*180 | 1840 | 980 | S150 | 354 | 2190 | 8.00V-20 | 430 | 335 | 281 |
| BPW-023 | 16.000 | S420*220 | 1850 | 980 | S150 | 376 | 2240 | 8.00V-20 | 475 | 335 | 281 |
| BPW-024 | 18.000 | S420*220 | 1850 | 980 | S150 | 376 | 2240 | 8.00V-20 | 485 | 335 | 281 |
| BPW-029 | 20.000 | S420*200 | 2242 | 1000-1060 | S150 | 260 | 2720 | 8.50V-20 | 745 | 335 | 281 |
KIC Trailer Axles:
|
Max Capacity (kg) |
Cam Brake Series * Width(mm) |
Track TR (mm) |
Spring Seat Installation (mm) |
AxleBeam (mm) |
Center Distance of Chamber (mm) |
Studs (mm) |
PCD (mm) |
H (mm) |
Total Length (mm) |
Recommended Wheel |
Weight (kg) |
| 13,000 | S420*200 | 1969 | 920-960 | 127*16 | 300 | 10*M22*1.5 ISO | 335 | 280.3 | 2300 | 7.50V-20 | 390 |
| 13,000 | S420*200 | 1969 | 920-960 | 127 | 300 | 10*M22*1.5 ISO | 285.75 | 220 | 2300 | 7.50V-20 | 390 |
| 13,000 | S420*200 | 1969 | 920-960 | 127 | 300 | 10*M22*1.5 ISO | 285.75 | 220 | 2300 | 7.50V-20 | 380 |
| 13,000 | S420*200 | 1969 | 920-960 | 127 | 300 | 10*M22*1.5 ISO | 335 | 280.3 | 2300 | 7.50V-20 | 380 |
specification of fuwa type trailer axles:
Model |
Capacity (kg) |
Track TR (mm) |
Spring seat installation (mm) |
Axle Beam (mm) |
Center distance of Chamber (MM) |
Total Length (mm) |
Recommended wheel |
Weight (kg) |
S Cam Brake (mm) |
Wheel fixing Studes (mm) |
PCD (mm) |
H (mm) |
| Fuwa-011 | 10.500 | 1820 | ≤435 | 0 127 | 368 | 2165 | 7.50T-20 | 360 | S420*180 | 10*7/8″-11 BSF | 335 | 281 |
| Fuwa-012 | 13.000 | 1840 | ≤455 | S 150 | 388 | 2185 | 7.50V-20 | 365 | S420*180 | 8*M20*1.5 JAP | 335 | 221 |
| Fuwa-013 | 16.000 | 1850 | ≤455 | S 150 | 354 | 2205 | 8.00V-20 | 425 | S420*220 | 10*M22*1.5 ISO | 335 | 281 |
| Fuwa-016 | 16,000 | 1850 | ≤455 | round 127 | 354 | 2185 | 8.00V-20 | 420 | S420*220 |
10*M22*1.5 ISO |
335 | 281 |
| Fuwa-017 | 16,000 | 1850 | ≤455 | square 150 | 354 | 2205 | 8.00V-20 | 425 | S420*220 |
10*M22*1.5 ISO |
335 | 281 |
We are OEM factory for various of trailer parts, trailer axles, trailer fifth wheel, trailer suspension, trailer landing gear, trailer king pin, and its related parts.:
Specification of York trailer axle
| Brake Size | Wheel fixing | Capacity |
NO.*Size of wheel studs * PCD |
| 420*180 | JAF | 12T | 8*M20*285 |
| 420*220 | ISO | 16T | 10*M22*335 |
Our factory provices products:
Wheel rim: Tube type , different size for truck, semi-trailer
Axle: American type & German type with different capacity.
Leaf Spring: Conventional and parabolic type with different size.
5th wheel & King pin: 2'' & 3.5'', Forging type
Suspension: 1axle, 2axle & 3axle with different steel plate thickness, Bpw type,American type
Air Suspension: 1axle, 2axle & 3axle with or without lifting
Bogie: 24tons, 28tons, 32tons,drum and spoke type
Landing Gear: Gear outside & Gear inside with capacity 25tons, 28tons, 30tons and 35tons
Air Chamber: T14, T16, T24, T30, T24T30, T24T24, T30T30
Brake shoe:420*180,420*200,420*220
Drake drum:12T ,14T,16T,18T etc.
Slack adjuster: manual and automatic slack adjuster
Packing & shipping
The product will be shipped within 2-3 days after the receipt of your payment.
Maintenance method:
1, keep the axle clean when installation, avoid mixed with foreign body
2, Replace lubricating oil regularly.
Our produce Features:
1, Special heat-treated, low-alloy steel axle beam, offers more stability, greater capacity and lighter weight.
2, Forged camshafts with hardened wear surface.
3, Solid inserted spindle and bearing journals laser heat treated, provide superior fatigue capability.
4, High performance premium non-asbestos brake linings, extend serivice life.
5, Easy for ABS installation.
Comany information: Shijiazhuang Zhong Run Machinery Manufacturing Co.,Ltd
Shijiazhuang Zhong Run Machinery Manufacturing Co.,Ltd local in economic and technical development Zone in Hebei Province.
We are the biggest professional and experienced manufacture of semi trailer parts in China.
Superior quality and good afer-sale service is our forever pursuit.
We export products to all over the world.
Expecting to have long cooperation with you.
The process flow of axle installation
Material Processing→welding→Painting→assembling
Our certification:
Our trailer axle part you may interested.
We are manufacture for various of trailer parts, trailer axles, trailer fifth wheel, trailer king pin, trailer landing gear, trailer suspension are all in our production range:
Wheel rim: Tube type , different size for truck, semi-trailer
Axle: American type & German type with different capacity.
Leaf Spring: Conventional and parabolic type with different size.
5th wheel & King pin: 2'' & 3.5'', Forging type
Suspension: 1axle, 2axle & 3axle with different steel plate thickness, Bpw type,American type
Air Suspension: 1axle, 2axle & 3axle with or without lifting
Bogie: 24tons, 28tons, 32tons,drum and spoke type
Landing Gear: Gear outside & Gear inside with capacity 25tons, 28tons, 30tons and 35tons
Air Chamber: T14, T16, T24, T30, T24T30, T24T24, T30T30
Brake shoe:420*180,420*200,420*220
Drake drum:12T ,14T,16T,18T etc.
Slack adjuster: manual and automatic slack adjuster
— FAQ —
• Why should you choose us?
Powerful factory, giving the competitive price
1.5 years warranty and 7*24 online after-sale service
CE certification
Strong OEM capability available.
• Do you accept small order?
We would like to grow up with all clients whatever big or small.
Any question, please kindly contact me directly anytime.thanks.
