Automatic Stainless Steel Mini Home Use Peanut Oil Press Machine

Automatic Stainless Steel Mini Home Use Peanut Oil Press Machine photo-1
Automatic Stainless Steel Mini Home Use Peanut Oil Press Machine photo-2
US$ 1,000 - 8,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Usage:
Olive Oil
Type:
Other, Cold & Hot Pressing Machine
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Usage Olive Oil
Type Other, Cold & Hot Pressing Machine
Automatic Grade Automatic
Production Capacity 98%
Place of Origin Henan, China
Brand Name Telon
Model Number TL-100
Voltage 220V/380V
Power(W) 7.5kw
Dimension(L*W*H) 1700*1100*1600mm
Weight 1100kg, 1100 kg
Certification ISO
After-sales Service Provided Engineers available to service machinery overseas
Product Description

Raw materials of oil press machine:

This type oil press machine collect advanced technology, and its materials can be sesame seed, peanut seed, rape seed, cotton seed, sunflower seed, coconut, soybean seed, tea seed and so on.

Parameter

Technical parameter of oil press machine:

Model
TL-80
TL-100
TL-120
TL-1`50
Diameter of worm section
80mm
100mm
120mm
150mm
Rotary speed of worm section
50-60 r/min
40 r/min
36 r/min
45 r/min
Diameter of inscribed circle of press boring
82mm
102mm
122mm
152mm
Motor
Main frame
5.5 KW
7.5 KW
11 KW
15 KW
Vacuum pump
0.55 KW
0.75 KW
1.1KW
1.1 KW
heater
3 KW
3 .5KW
4 KW
6 KW
Capacity
80-150kg/h
150-250kg/h
260-400kg/h
230-500kg/h
Weight
780kg
1100kg
1500kg
1800kg
Overall dimension (L*W*H)
1800*1300*1750
1980*1450*1800
2100*1680*1750
2300*1700*1800

Characteristics of oil press machine:

1. Higher oil yield: directional pressure-bearing, multilevel promotion, the oil yield increase by 10%-30%
2. High productivity: It strengthens feeding system and increases the advancing speed, so the working efficiency will be improved by more than 30%
3. Automatic temperature control: It can control the temperature automaticly when it is pressing, and it is built in vacuum shunt, the oil and residue can be apart.
4. Filter oil automatically: Using air negative pressure principle and Vacuum diversion technology, the oil and residue can be separated effectively.
5. Convenient and safe: concise structure, small occupation area, it adopt the fully enclosed protection, convenient and safe operation.
6. Durable in use: The machine body use the high quality wear-resistant steel and anti-fatigue casting, stable performance and long-time and continuous working
7. The coconut oil mill surface is coated by lastest material and it is good adhesion, heat resistant, greasy resistant, not only elegant appearance, but also clean.

8. Hot press or cold press is all ok.

Oil Yield

The oil yield of several kind of raw materials:

Materials/ Parameter
Oilproductivity(%)
Material bread thick
Residual oil rate(%)
Sesame
45-55
1.0-1.5
≤6
Peanut
40-50
0.5-2.0
≤6
Rapeseed
30-45
0.8-1.8
≤6
Sunflowerseed
32-42
1.0-1.5
≤6
Soybean
12-18
0.8-1.5
≤6
cottonseed
11-25
1.0-2.0
≤6
Walnut
42-52
0.8-1.5
≤6
Flax
32-38
1.0-1.8
≤6
Tea seed
26-38
1.0-2.0
≤6
