Top quality woven roll brake lining
| Part Name | woven roll brake lining |
| Brand packing | we can make brake lining rolls as per customer's brand or drawings. |
| Payment | T/T30% deposite, 70% balance one week before delivery |
| Delivery Date | 30 days after receiving deposite |
Woven roll brake lining with resin
1. Standard: GB/T11834-2000
2. Specification: (4-20)mm x (30-350)mm
3. Performance: high intensity and wears ability
4. Application: deceleration for the braking of the ship and other heavy machinery
5. Remarks: Material, color and length can be made according your request.
Test Report For Woven Resin Brake Lining Roll | ||
| Temperature | Coefficient of Friction | Wear Rate(Cm3/N.m) |
| 100°C | 0.40-0.65 | ≤0.3×10-7 |
| 150°C | 0.35-0.65 | ≤0.5×10-7 |
| 200°C | 0.30-0.60 | ≤0.7×10-7 |
Regular order sizes of woven roll brake lining
| Item | Width(mm) | Thickness(mm) | Length(m) | Rolls |
| 1) | 35 | 4 | 5 | 500 |
| 2) | 45 | 5 | 5 | 500 |
| 3) | 50 | 5 | 5 | 200 |
| 4) | 50 | 6 | 5 | 200 |
| 5) | 57 | 5 | 5 | 200 |
| 6) | 57 | 6 | 5 | 200 |
| 7) | 57 | 6 | 5 | 100 |
| 8) | 76 | 9.5 | 7.5 | 100 |
| 9) | 100 | 9.5 | 7.5 | 100 |
| 10) | 125 | 9.5 | 7.5 | 100 |
| 11) | 152 | 9.5 | 7.5 | 100 |
| 12) | 100 | 12 | 7.5 | 100 |
| 13) | 152 | 12 | 7.5 | 100 |
| 14) | 76 | 12 | 7.5 | 100 |
| 15) | 200 | 12 | 7.5 | 100 |
| 16) | 228 | 12 | 7.5 | 100 |
Length of each roll: 7.5 meter, 10 meter, 15 meter; as per your request | ||||
Jiangsu Great Industrials Group Corp.Ltd.
—— Factory Workshop & Sample Showroom
We're manufacturing all brake system, clutch system parts and friction material of brake and clutch, include brake linjings, brake Lining in rolls , with perfect quality since last 22 years;our brake lining roll products covers the world market Europe,South-east Asia,Mid-East and African Countries;
We have high quality non-asbestos material brake lining rolls in diffrerent colors. Types include rubber moulded brake lining roll, resin woven brake lining roll, semi-metallic brake lining roll etc. rubber brake lining roll with black, grey, white, yellow color; and woven brake lining roll with light yellow, reddish brown, dark brown, white color. We have the ability to develop any new quality and materials to new market.
If you hold interest and need further information of our brake system parts, don't hesitate to contact us!
