EH Single cylinder diesel engine
The scope of application
Widely used in four wheel tractor , All kinds of transport machinery , Pump unit , Irrigation machinery , Construction machinery , Generator Set, Small engineering machinery and other fields .
The structure of EH series single cylinder diesel engine
1. Using P type injector, optimizing the combustion process, fuel saving, low emission, low smoke
2. he alloy steel forging crankshaft, compact structure, good reliability, high safety factor .
3. The use of nylon alloy water tank, high strength, good compliance, can effectively avoid water tank cracking; corrosion resistance, wear resistance, long service life, light weight, material saving and energy saving;
4. The balance shaft adopts a cylindrical roller bearing, improve the bearing capacity
5. Good interchangeability
the EH performance of single cylinder diesel engine
1. Strong power, strengthen the fuel system, optimization of combustion process, fuel saving, low emission, low smoke .
2. The same fuel consumption power of single cylinder engine (km/h) minimum, minimum weight, minimum volume .
The main technical parameters of EH series single cylinder diesel engine
95 120
| model | Engine type | Combustion chamber type | Bore (mm) | stroke (mm) | output volume (L) | Rated power (kw/r/min) | Maximum torque (N.m) | Maximum torque speed (r/min) | Calibration of light fuel consumption(g/kw.h) | Idle(r/min) | Compression ratio | Start mode | Net weight(kg) | Size(mm |
| EH10 | ingle cylinder, horizontal, evaporation, water cooled,4-stroke | Direct injection | 85 | 0.539 | 7.5/2400 | ≥33.5 | ≤1920 | ≤240 | ≤800 | 19 | hand tar or electric starter | 96 | 655×381×570 | |
| EH12 | 90 | 95 | 0.604 | 8.8/2400 | ≥39.2 | ≤1920 | ≤240 | ≤800 | 19 | 96 | 655×381×570 | |||
| EH18 | 100 | 0.942 | 12.7/2200 | ≥61.7 | ≤1760 | ≤240 | ≤800 | 17 | 145 | 836×410×640 | ||||
| EH20 | 105 | 120 | 1.039 | 14.7/2300 | ≥68.4 | ≤1840 | ≤240 | ≤800 | 17 | 150 | 836×410×664 | |||
| EH24 | 115 | 120 | 1.246 | 17.2/2300 | ≥83.7 | ≤1760 | ≤240 | ≤800 | 17 | 185 | 875×450×688 | |||
| EH32 | 130 | 125 | 1.659 | 23/2300 | ≥111.8 | ≤1760 | ≤240 | ≤800 | 16.5 | 212 | 916×475×709 | |||
| EH36 | 135 | 125 | 1.789 | 25/2200 | ≥121.5 | ≤1760 | ≤240 | ≤800 | 16.5 | 230 | 916×475×709 |
Packing&Shipping
plywood box
Within 15 days
OUR ADVANTAGE:
1. Professional supply with certification: CCC, ISO and so on
2. Perfect quality program. 100% test before delivery for every engine.
3. One year guarantee.
4. OEM service.
5. Creative design team and first class quality equipments.
6. Design and Producing be customized.
FAQ
1.Where is the factory ?
We are in Shandong Province,China.
Welcome to visit factory !
2. How many years your company ?
We spcilized in Machinery parts 12 years experience ,now we have more than 1000 workers and more than 40 toppest techinical engineers.
3. How about your price in the similar suppliers ?
Price is our big advantage ! Let 's enlarge big market together !
4.If you have warranty about the quality ?
Of course,we have it .
Our credit guarantee service system can vouch for you
5. What about the payment ?
T/T ,L/C,D/P, Western Union
