US$ 1,000 - 3,000
MOQ: 15 Units
Key Specifications
Get Latest Price
Use For:
Cargo
Driving Type:
Motorized
Displacement:
> 250cc
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Use For
Cargo
Driving Type
Motorized
Body Type
Open
Certification
Other, ISO9001
Brand Name
FOTON,WAW,BOTA
Place of Origin
Shandong, China
Model Number
Diesel tricycle 2B10100
Size
3443x1200x1379MM
Diesel tricycle 2B10100
Main Features
Newly optimize to design the whole vehicle, whose leaf spring externally spans the vehicle frame to suit for borehole operation, and whose frame is sturdy in construction with large bearing capacity; thicken the sideboard and base plate of the container, which is designed as a frame type skeleton shape for long service life.
As a high-end brand of mine truck in the industry, the product is suitable for the uses in coal mines, iron ores and construction works.
As a high-end brand of mine truck in the industry, the product is suitable for the uses in coal mines, iron ores and construction works.
Specification
| Model | Specification | parameter |
| 2B10100 | loading capacity | 2 tons |
| Overall dimensions of vehicle (mm) | 3443*1200*1379 | |
| dimensions of the cargo (mm) | 1800*1200*400 | |
| wheel base (mm) | 2313 | |
| wheel track (back) (mm) | 1220 | |
| type number | 3 | |
| steel spring number) | 13(7+6) | |
| width of cabin(mm) | 1100 | |
| rated power (Hp) | 18 | |
| Displacement ( L) | 0.996 | |
| curb weight( kg) | 940 | |
| rear overhang( mm) | 820 | |
| max speed | 50 | |
| engine | 1115 | |
| tire size (F/R) | Front:450-14 | |
| Rear :6.50-16 | ||
| brake system | Vacuum Booster | |
| gear box | 3*2+2 | |
| brake system | foot brake; hand brake | |
| gear box | 238 | |
| rear axle | Hydraulic full floating | |
| dump equipment | Yes | |
| Qty in 40(units) | SKD15 | |
| color | red |
