Main Features
Adopt extra-heavy high-tensile damping spring damper in order for stronger load capacity and stability.
The disc and handle turning modes are optional, which facilitates to have larger power compared with a motorcycle and be more suitable for agricultural operation.
Adopt power matching, which not only improves the output power of the motor efficiently, but also lowers the fuel consumption, showing stronger and more economical characteristics.
Adopt ergonomic techniques of automotive design in order for more comfortable drive and ride.
The auto beam is manufactured by steel and configured by extra-heavy suspension for the improvement of load capacity and a safer drive.
Adopt stamping integrative lumber-core containers, which have better treatment processes and more reliable performance with no rust.
Specification
Model | 7YP850-14D | ||
Cabin | Wind shield | ||
Main dimensions | Overall dimension (LXWXH)mm | 3800×1380×1420 | |
Dimension of the cargo body (LXWXH)mm | 2150*1300*350 | ||
Wheel base | 2520 | ||
wheel track(front/rear)mm | 1200 | ||
Min.ground clearance | 250 | ||
Weight | Curb weight (kg) | 870 | |
Rated payload (kg) | 800 | ||
person in the cabin | 2 | ||
Gross vehicle weight(kg) | 1800 | ||
Overall performance | Max.speed(km/h) | 47.2 | |
Max.slope of climb(%) | 15 | ||
Minturing radius(m) | 3.49 | ||
Engine | Engine type | CCZS1100 | |
Displacement (L) | 0.903 | ||
Rated horsepower (kg.m/rpm) | 16.5 | ||
Steering gear type | Mechanical | ||
Service brake and boosting Type | mechanical | ||
wheels and tyre size | Front wheel | 50014 | |
Rear wheel | 65016 | ||
Electric device | Rated voltage | 12 | |
Battery | 6-QW-120MF | ||
Optional device | No | ||
Qty for one 40HQ | CKD | 16 units | |
