Specifications
mini tractor for sale 10-20HPcan attach kinds of implements :Single share Plough, double share plough, rotary tiller etc
mini tractor for sale
DETAILED SPECIFICATIONS |
|
|||
|
|
|
|
|
TYPE |
Unit |
HR120 |
|
|
Driving type |
4x2WD |
|
|
|
Overall dimensions (L*W*H) |
mm |
1760x910x1000 |
|
|
rated traction force |
KN |
2.9/3/3.2 |
|
|
Net weight |
kg |
600 |
|
|
Clutch |
one stage,single disk,dry,constant mesh |
|
||
Front tyre |
400-12 |
|
||
Back tyre |
650-16 |
|
||
Front wheel track |
mm |
730-780(adjustable) |
|
|
Rear wheel track |
mm |
700-800 (adjustable) |
|
|
wheel base |
kPa |
1080/1150 |
|
|
ENGINE |
|
|||
Model |
|
JD190/192/R195 |
|
|
Transmission oil capacity |
L |
1.5 |
|
|
Rated speed |
rpm |
2300 |
|
|
gear box |
|
(3+1)*2 |
|
|
Engine type |
|
single cylinder, horizontal,4-stroke and direct injection |
||
starting model |
|
electric starter system |
|
|
rated power |
kw |
7.7/8.8/11 |
|
|
Clutch |
one stage,single disk,dry,constant mesh |
|
||
We can produce from 7-20HP walking tractors.
The power tiller can attach many kinds of implements Single share Plough, double share plough, rotary tiller, etc.
| Model | HR121 | HR151 | ||
| Overall dimensions (lxwxh)mm | 2680x960x1250 | 2680x960x1250 | ||
| Wheel track (mm) | 800 740 640 500 | 800 740 640 500 | ||
| Ground clearance (mm) | 210 | 210 | ||
| Tyres | 6.00-12 | 6.00-16 | ||
| Construction weight (kgs) | 375 | 505 | ||
| Speed (km/h) |
Forward |
1.54,2.75,4.51 5.83,10.34,16.83 |
1.54,2.75,4.51 5.83,10.34,16.83 |
|
| Reverse | 1.20,4.18 | 1.20,4.18 | ||
| Rotary Tiller speed (rpm) |
High | 275 | 275 | |
| Low | 219 | 219 | ||
| Diesel engine |
Model | 195 | 1100 | |
| Type |
Singlecylinder,horizontal,4 stroke Water cooling Diesel |
Singlecylinder,horizontal,4 stroke Water cooling Diesel |
||
| Rated power kw(hp) | 8.82(12) | 11.03(15) | ||
| Rated speed (rpm) | 200 | 2300 | ||
| Net Weight (kgs) | 190 | 200 | ||
KEY SPECIFICATION
1. Two wheels tractors be supplied from 4.85KW ( 6hp) to 14.70kw (20hp)
2. Features: Compact,Agile,Light,Reliable,Convenients,High Quality.
3.Suitable for paddy fields,upland plains,moutainous and hilly areas.and for plough,rotary tillage,sow,threshing ,suction and so on.
4.Equipped with lightings for dirving at night.
5.Can be used as a stationary power source for drainage and irrigation.
6.With quick coupling,easy to chang farming implements. Cultivator,mower,trailer,water pump,power tiller,snow blower,rotary plough,ect.
7. Different product colors is optional, to adapt to different market
OUR RANGE
1. TOW WHEELS WALKING TRACTOR.FROM 6HP TO 20HP
2. FOUR WHEELS TRACTORS FROM 20HP TO 100HP
3. IMPLEMENTS: CULTIVATOR,PLOUGH,ROTARY TILLER, Hole Digger, PLANTER.HARVEST AND SO ON.
4. TRAILER
WHY CHOOSE US
1. Professional supply with certification: CCC, ISO,CE,DOT and so on
2. Perfect quality program. 100% test before delivery
3. One year guarantee.
4. OEM cervice.
5. Creative design team and first class quality equipments.
6. Design and Producing be customized.
7. Flexible payment. T/T L/C D/P,WESTERN UNION be accept.
