1BQX Disc harrow
disc harrow offset disc harrow 1BQX
1. Using high quality materials
2.Good product quality
3. Used for a long time
20-260 hp Tractor disc harrow 1BQX
Description:
The 1BQX series mounted light-duty disc harrows are suitable for pulverized loosening colds after ploughing and for planning the land before sowing on cultivated land.The machines can mix up soil and fertilizer and clear away the stump of plants on light soil and prepair seed bed for planting.
Customers can choice diffirent implments and tractors as market request in one same container.
| Type | 1BQX-1.1 | 1BQX-1.3 | 1BQX-1.5 | 1BQX-1.7 | 1BQX-1.9 | 1BQX-2.3 | |||||
| Name | The 12-blades mounted harrow | The 14-blades mounted harrow | The 16-blades mounted harrow | The 18-blades mounted harrow | The 20-blades mounted harrow | The 24-blades mounted harrow | |||||
| Overall dimensions(mm) | L | 1590 | 1590 | 1905 | 1905 | 2305 | 2650 | ||||
| W | 1230 | 1440 | 1600 | 1820 | 2000 | 2450 | |||||
| H | 830 | 830 | 1118 | 1118 | 1118 | 1280 | |||||
| ong width(m) | 1.1 | 1.3 | 1.5 | 1.7 | 1.9 | 2.3 | |||||
| Working depth(cm) | 8-14 | ||||||||||
| No.of disc | 12 | 14 | 16 | 18 | 20 | 24 | |||||
| Disc spacing(mm) | 460 | ||||||||||
| Thickness of disc(mm) | 3 | ||||||||||
| Disc soacing(mm) | 200 | ||||||||||
| Weight(kg) | 200 | 220 | 240 | 260 | 300 | 500 | |||||
| Producivity(ha/h) | 0.7 | 0.84 | 0.97 | 1.1 | 1.3 | 1.5 | |||||
| Linkage | three-point mounted | ||||||||||
| Trans.Clearance(mm) | ≥280 | ≥280 | ≥200 | ≥200 | ≥200 | ≥200 | |||||
| Matched power(kw) | 8.8-14.7 | 11-18.4 | 14.7-25.7 | 20.6-29.4 | 25.7-36.8 | ≥40.4 | |||||
Model |
unit |
1BJX-1.6 |
1BJX-1.8 |
1BJX-2.0 |
1BJX-2.2 |
1BJX-2.4 |
1BJX-2.5 |
Working width |
mm |
1600 |
1800 |
2000 |
2200 |
2400 |
2500 |
Working depth |
mm |
140 |
|
|
|
|
|
Q’ty of disc |
|
14 |
16 |
18 |
20 |
22 |
24 |
Total weight |
kg |
350 |
380 |
420 |
470 |
540 |
650 |
Matched power |
hp |
30 |
40 |
50 |
60 |
70 |
80 |
Linkage |
|
Three point suspension I type |
Three-point suspension II type |
||||
Main Feature
1.Suit for 20-260hp
2.Diesel eingine ,compact ,agile ,ligh ,reliable,convenients,Excellent quality
3.Suitable for upland plaines ,moutainous and hilly areas .
4.Equipped with four wheel tractors.
5.with quickly coupling ,easy to change.
6.The different agricultural implements can choice.
7.Every year export more than 40000sets ,the products are welcome by the market.
FACTORY
<img
WHY CHOOSE US
1. Professional supply with certification: CCC, ISO,CE,DOT and so on
2. Perfect quality program. 100% test before delivery
3. One year guarantee.
4. OEM cervice.
5. Creative design team and first class quality equipments.
6. Design and Producing be customized.
7. Flexible payment. T/T L/C D/P,WESTERN UNION be accept
8. Small order and big regullar order all welcome
