water pump
* Flexible shaft pumps are mini centrifugal pumps of single type.
* Widely used for pumping and draining in construction building sites, tunnels, culverts, also for sewage discharging in industry, irrigation on farmland and etc..
* They are powered by petrol or diesel engines, mini-types can also use vibrator motor as their power.
* These pumps are reliable and available in small size and light weight. The compact design saves working space.
Features
* Fitting with the iron casting impeller and volute casing for increasing endure of pump .
* Coupled to a reliable gasoline engine
* the tightly fitting impeller and voluter casing for excellently capacity and head
* safely , light in weight conveient for moving and operating
Technical Specification
Model |
HGP50-32-6 |
HGP50-36-6 |
HGP80-32-6 |
HGP80-36-6 |
|
Discharge Diameter(mm) |
50(2") |
50(2") |
80(3") |
80(3") |
|
Dia.of Flexible Hose(mm) |
32 |
36 |
32 |
36 |
|
Pump Lift(m) |
20 |
20 |
18 |
18 |
|
Max.Flow (m3/hr) |
25 |
25 |
28 |
28 |
|
Weight(with 6m hose)(kg) |
16.5 |
20.5 |
17 |
21 |
|
Rotary(rpm) |
2850 |
||||
Hose Length(m) |
6 |
||||
Power Type |
Driven by gasoline engine,diesel engine or electric motor |
||||
Dimension(cm) |
Pump (cm) |
28×22×25 |
|||
Hose (cm) |
83×65×7 |
||||
