Mf 385 2wd Tractor Pakistan

Specifications

We are the Sole & Authorized Distributor Of Massey Ferguson & Millat Tractors.
We Have the Different Quality of Tractors.

We have different Design and Types.
We have the Best and A+Grade Quality Tractors & also their

Implements

• EDGE OVER 2WD
• Traction (30% More)
• Drawbar Power (16% More)
• Drawbar Pull (34% More)
• Tyre Wear (15% less)
• Fuel Efficiency (15% More)
• Field Work Speed (13-20% More)







PERFORMANCE:
Rated Engine Power*: 85 BS HP (58.2 KW) @ 2200 rev/min**: 85 DIN PS (52.3 KW) Max. Engine Torque: @ 1400 rev/min is 268 Nm (218 lbf. ft) Max. P.T.O. HP: @ rated Engine Speed*** 64.0 Ps (47.1 KW) * Certified to BSAU 141 a ** DIN 70020 *** Manufacturer's Estimate
ENGINE:
Make/Type: Perkins/A 4.236 No. of Cylinders: 4 Injection: Direct Bore: 98.4 mm (3.875 in) Stroke: 127.0 mm (5.0 in) Capacity: 3.86 Liter (236 cu. in) Compression Ratio: 16.0:1 Starting Aid: Thermostat Cooling: Water Air Cleaner: Oil Bath Air pre-cleaner: Over-bonnet, Centrifugal Fuel Filter: Dual, High Capacity Exhaust: Vertical, Muffler under Bonnet
ELECTRICS:
Voltage: 12 Volt, Negative Earth Battery : 96 Amp hour Alternator/Starter: 45 Amp/2.2 KW Light: Head Lights, Side Lights, Brake Light, Direction Indicators, Rear Work Lamp Safety Start: Transmission & PTO Other: Horn
CLUTCH:
Type: Dual Diameter: 305 x 254 mm (12 in x 10 in) Lining Material: Cerametalic or Asbestos
TRANSMISSION:
Type: Sliding Spur No. of Gears: 8 Forward, 2 Reverse Road Speed @ rated engine speed with 18.4/15 - 30 rear tyres: Gear       Speed mile/h (km/h)   Forward  Forward Forward Forward Forward Forward Forward Forward Reverse Reverse   1 1.7 (2.5) 2 2.3 (3.7) 3 3.2 (5.1) 4 4.2 (6.8) 5 6.4 (10.4) 6 9.4 (15.2) 7 12.9 (20.8) 8 17.3 (27.9) 1 2.1 (3.5) 2 8.8 (14.1)
HYDRAULICS:
Functions: Draft, Piston, and Response Control Constant Pumping Pump Type: Piston Max. Output: 16.7 liter/min (3.67 imp. gal/min) Max. Lift Capacity: 2145 Kg (4728 lb) At Lower Link Ends, Links Horizontal 3 - Point Linkage: Cat 1 & 2 Interchangeable Balls
WEIGHTS AND DIMENSIONS:
(With 12.4 - 24 Front and 18.4/15 - 30 Pressed Rear Wheel with Full Fuel, Oil and Water) Weight Front: 1429 Kg (3144 lb.) Weight Rear: 1582 Kg (3488 lb.) Weight Total: 3011 Kg (6638 lb.) Overall Length: 3810 mm (150 in) Width ? Min.: 1871 mm (73.7 in) Height-: Over Exhaust: 2485 mm (97.8 in) Over Steering Wheel: 1781 mm (70.1 in) Wheel Base: 2350 mm (92.5 in) Turning Circle: 8518 mm (335 in)
STEERING:
Type: Hydrostatic Steering Wheel: Fixed, Padded
BRAKES:
Type: Oil Immersed Disc Brakes, 4 Plates Braking Area: 1774 sq. cm (275 sq. in) Operation: Hydraulic Parking Brake: Hand Lever Operated
INSTRUMENTATION:
Gauges: Tachometer/Hour Meter, Fuel, Water, Temperature, Speed Indicator Warning Lights: Direction Indicators, Electric Charge, Head Light Main Beam, Low Engine Oil Pressure, 4WD indication Light
WHEEL AND TYRES:
Front: 12.4 ? 24 (6PR) Pressed Rear: 18.4/15 - 30 (6PR) Pressed TRACK ADJUSTMENT: Front: 1376 - 1944 mm (216 mm high axle) (54 - 76 in) Rear: ? pressed: 1423 - 2134 mm (56 - 84 in)
STANDARD EQUIPMENT:
- Chain Stabilizers - Weight Frame without Weights - Set of Tools - Top Link - Operator's Manual - Cat. 1 Balls - Check Chains
