Massey Ferguson Mf 385 4wd Tractors Pakistan Assembled Farm Machinery

Massey Ferguson Mf 385 4wd Tractors Pakistan Assembled Farm Machinery thumbnail-1
Massey Ferguson Mf 385 4wd Tractors Pakistan Assembled Farm Machinery photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
4WD
Contact Supplier Request Quote Chat Now
Murshid Farm Industries
Payment & Shipping
Payment Methods:
Port of Shipment:
Karachi-Pakistan
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 4WD
Usage Farm Tractor
Certificate EPA
Brand Name Massey Ferguson
Model Number MF-385 4WD 85HP
Place of Origin Pakistan

Specifications

We are the Sole & Authorized Distributor Of Massey Ferguson & Millat Tractors.
We Have the Different Quality of Tractors.

We have different Design and Types.
We have the Best and A+Grade Quality Tractors & also their

Implements


  • EDGE OVER 2WD
  • Traction (30% More)
  • Drawbar Power (16% More)
  • Drawbar Pull (34% More)
  • Tyre Wear (15% less)
  • Fuel Efficiency (15% More)
  • Field Work Speed (13-20% More)







PERFORMANCE:
Rated Engine Power*: 85 BS HP (58.2 KW)
@ 2200 rev/min**: 85 DIN PS (52.3 KW)
Max. Engine Torque:
@ 1400 rev/min is 268 Nm (218 lbf. ft)
Max. P.T.O. HP:
@ rated Engine Speed*** 64.0 Ps (47.1 KW)
* Certified to BSAU 141 a
** DIN 70020
*** Manufacturer's Estimate

ENGINE:
Make/Type: Perkins/A 4.236
No. of Cylinders: 4
Injection: Direct
Bore: 98.4 mm (3.875 in)
Stroke: 127.0 mm (5.0 in)
Capacity: 3.86 Liter (236 cu. in)
Compression Ratio: 16.0:1
Starting Aid: Thermostat
Cooling: Water
Air Cleaner: Oil Bath
Air pre-cleaner: Over-bonnet, Centrifugal
Fuel Filter: Dual, High Capacity
Exhaust: Vertical, Muffler under Bonnet

ELECTRICS:
Voltage: 12 Volt, Negative Earth
Battery : 96 Amp hour
Alternator/Starter: 45 Amp/2.2 KW
Light: Head Lights, Side Lights, Brake Light, Direction Indicators, Rear Work Lamp Safety Start: Transmission & PTO
Other: Horn

CLUTCH:
Type: Dual
Diameter: 305 x 254 mm (12 in x 10 in)
Lining Material: Cerametalic or Asbestos

TRANSMISSION:
Type: Sliding Spur
No. of Gears: 8 Forward, 2 Reverse
Road Speed @ rated engine speed with 18.4/15 - 30 rear tyres:

Gear       Speed mile/h (km/h)
  Forward
Forward
Forward
Forward
Forward
Forward
Forward
Forward
Reverse
Reverse
  1 1.7 (2.5)
2 2.3 (3.7)
3 3.2 (5.1)
4 4.2 (6.8)
5 6.4 (10.4)
6 9.4 (15.2)
7 12.9 (20.8)
8 17.3 (27.9)
1 2.1 (3.5)
2 8.8 (14.1)

HYDRAULICS:
Functions: Draft, Piston, and Response Control
Constant Pumping
Pump Type: Piston
Max. Output: 16.7 liter/min
(3.67 imp. gal/min)
Max. Lift Capacity: 2145 Kg (4728 lb)
At Lower Link Ends,
Links Horizontal
3 - Point Linkage: Cat 1 & 2 Interchangeable Balls

WEIGHTS AND DIMENSIONS:
(With 12.4 - 24 Front and 18.4/15 - 30
Pressed Rear Wheel with Full Fuel, Oil and Water)
Weight Front: 1429 Kg (3144 lb.)
Weight Rear: 1582 Kg (3488 lb.)
Weight Total: 3011 Kg (6638 lb.)
Overall Length: 3810 mm (150 in)
Width ? Min.: 1871 mm (73.7 in)

Height-:
Over Exhaust: 2485 mm (97.8 in)
Over Steering Wheel: 1781 mm (70.1 in)
Wheel Base: 2350 mm (92.5 in)
Turning Circle: 8518 mm (335 in)

STEERING:
Type: Hydrostatic
Steering Wheel: Fixed, Padded

BRAKES:
Type: Oil Immersed Disc Brakes, 4 Plates
Braking Area: 1774 sq. cm (275 sq. in)
Operation: Hydraulic
Parking Brake: Hand Lever Operated

INSTRUMENTATION:
Gauges: Tachometer/Hour Meter,
Fuel, Water, Temperature, Speed Indicator
Warning Lights: Direction Indicators,
Electric Charge,
Head Light Main Beam,
Low Engine Oil Pressure,
4WD indication Light

WHEEL AND TYRES:
Front: 12.4 ? 24 (6PR) Pressed
Rear: 18.4/15 - 30 (6PR) Pressed TRACK ADJUSTMENT:
Front: 1376 - 1944 mm
(216 mm high axle) (54 - 76 in)
Rear: ? pressed: 1423 - 2134 mm
(56 - 84 in)

STANDARD EQUIPMENT:
- Chain Stabilizers
- Weight Frame without Weights
- Set of Tools
- Top Link
- Operator's Manual
- Cat. 1 Balls
- Check Chains
