MASSEY FERGUSON MF FARM TRACTORS

FOB Price

US$ 12,500 - 13,000 / Unit

1 Unit(Min. Order)

Port Karachi
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Other
By wheel	Other, 2WD/4WD	Usage	Farm Tractor
Certificate	EPA	Brand Name	Massey Ferguson Tractor
Model Number	MF 240 / 260 / 275 / 350 / 375 / 385	Place of Origin	Pakistan

Product Description

Specifications

Sole & Authorized Distributor of Massey Ferguson & Millat Tractors, Manufacturer Exporter Best Quality Agricultural Implements

PERFORMANCE:

Rated Engine Power**75 BS HP
@ 2200 rev/min**(71 DIN PS) 58.2 KW
Max. Engine Torque @ 1400 rev/min 267 Nm (218 Lbf ft)
Max. P.T.O. HP @ rated Engine Speed*** 64.0 Ps (47.1 KW) * Manufacturer's Estimate

ENGINE:

Make/Type Perkins/A 4.41
No. of Cylinders 4
Injection Direct Injection Diesel
Bore 101mm
Stroke 127.0 mm (5.0 in)
Capacity 4.1 Liter
Compression Ratio 15.3:1
Starting Aid Thermostat
Throttle Control Hand and Foot
Cooling Water
Air Cleaner Oil Bath
Air pre-cleaner Over-bonnet, Centrifugal
Fuel Filter Dual, High Capacity
Exhaust Vertical, Muffler under Bonnet

ELECTRICS:

Voltage 12 V, Negative Earth
Batteries 2 Nos., 50 AH each
Alternator/Starter 40 Amp/2.2 KW
Light Head Lights, Side Lights, Brake Light, Direction Indicators, Rear Work Lamp
Safety Start Transmission & PTO
Other Horn

CLUTCH:

Type Dual
Diameter 305 x 254 mm (12 x 10 in)

POWER TAKE - OFF:

Type Live PTO
Speed 540 rev/min @ 1789 engine rev/min Single Speed
Shaft Diameter 35 mm (1.375 in)
No. of Splines 6

INSTRUMENTATION:

Gauges Tachometer/Hour Meter, Fuel, Water,Temperature, Speed Indicator,
Direction Indicators, Electric Charge, Head Light

Warning Lights Main Beam, Low Engine Oil Pressure

TRANSMISSION:

Type Sliding Spur
No. of Gears 8 Forward, 2 Reverse

Road Speed @ rated engine speed with 18.4/15 - 30 rear tyres:

Gear

Speed mile/h (km/h)

Forward
Forward
Forward
Forward
Forward
Forward
Forward
Forward
Reverse
Reverse

1 2.6
2 3.8
3 5.3
4 7.1
5 10.5
6 15.4
7 21.0
8 28.3
1 3.6
2 14.3

HYDRAULICS:

Functions: Draft Control
Piston Control
Response Control
Constant Pumping
Pump Type: Piston
Max. Output 16.7 litre/min
Max. Lift Capacity 207 bar (3000 lbf/in2)

BRAKES:

Type Oil Immersed Disc Brakes, 4 Plates
Braking Area 1774 cm2 (275 in2)
Operation Hydraulic
Parking Brake Hand Lever Operated

WHEEL and TYRES:

Front 7.50 - 16 (6PR) Pressed
Rear 16.9/14 - 30 (6PR) Pressed

TRACK ADJUSTMENT:

Front 1346 - 1854 mm
Rear-Pressed 1423 - 2134 mm 56 - 84 in)

WEIGHTS AND DIMENSIONS:

Weight Total 2200 Kg
Overall Length 3542 mm
Width ? Min. 1870 mm
Height-Over Exhaust 2480 mm
Over Steering Wheel 1815 mm
Wheel Base 2100 mm
Turning Circle 6900 mm (Less Brake)
Ground Clearance 405 mm (Under Gear Box)
