American Type 2 Axle Mechanical Suspension in China

Name: American Type 2 Axle Mechanical Suspension in China
Brand: WONDEE
Availability: InStock
Rating: 4.5 (68 reviews)

FOB Price

USD $350 - $400 / Set

5 Sets(Min.Order)

Supply Ability 2000 Set / Sets per Month
Port Xiamen/Qingdao
Payment Terms:T/T

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Parts:	Trailer Suspension	OEM No.:	Mechanical Suspension in China	Max Payload:	16T per Axle
Size:	Leaf Spring Spec:90169	Place of Origin:	Fujian, China	Brand Name:	WONDEE
Model Number:	SPZA2-2555006

Packaging Details

Mechanical Suspension in China Packing: 5 set/palet; CKD 60 set/20FCL

Product Description

Mechanical Suspension in China Main Dimension:

1.w*t*leaf no.:90*16*9 2.Height of Towing Plate: 1180 mm

3.Plate Thickness:6mm 4.Material: Steel

5.Certificate: ISO/TS16949,COC,CIQ,SONCAP

2-axle American type Suspension
Item No.	Plate Thickness	Height of Towing Plate	A1	B1	H	Leaf Spring Spec
Item No.	mm	mm	mm	mm	mm	wtleaf no
SPZA2-1855006	6	1180	473	443	185	90169
SPZA2-2355006	6	1230	523	493	235	90169
SPZA2-2555006	6	1250	543	513	255	90169
SPZA2-1855008	8	1180	473	443	185	90169
SPZA2-2355008	8	1230	523	493	235	90169
SPZA2-2555008	8	1250	543	513	255	90169

Following axles with 8 holes and 10 holes are waiting for you to choose:

1) 12 ton capacity axle

2) 13 ton capacity axle

3) 14 ton capacity axle

4) 16 ton capacity axle

With the earnest work of our 50 technicians, we have developed diversity of different sizes and types axles for various application.

Mechanical Suspension in China Spare Parts:


1.Frant Hanger	2.Control Arms Adjuster	3.Equalizer Hanger	4.Leaf Spring	5.Rear Hanger	6.Other Parts

Drawing Pictures about Mechanical Suspension in China :

Mechanical Suspension Features:

1. Semi-trailer suspensions

2.2-axle system, 3-axle system, 4-axle system, single point suspension systems are Available

3.Capacity for different requirements

4. Boogie according to special needs

5.Has passed the ISO and TS16949 standard authentication of international quality control system

6.Strict quality control system to assure our excellent product quality.

ducts are popular in the worldwide market, including North American, South American, European, African and Southeast Asian markets.

Mechanical Suspension More Information ( Just for Reference) :

1.The front, middle and rear spring hangers are made of high tensile low alloy steel plates (pressed and welded into structure) stronger but lighter than the old type.

2.The new design prevents the spring from shifting in a side way during running, The 90mm wide steel spring is made of high quality material.

3. The antifriction block (welded) is made of high tensile steel plate material (or #20cast steel) .

4. Its angle is in line with the unfolding direction between the steel plate spring and the antifriction block of the rocker arm.

5. The angle of the torque arm is scientifically adjusted. It can efficiently reduce the instant sliding distance between the tires and the ground, effectively lower friction of the tire, and increase the tire service life.

7.The torque arm bushing is made of urethane rubber. It has a buffering function to the instant abrasion in sliding shift of the tire.

8.The above features, plus a correct installation, reliably guarantee the verticality between the axle and the king pin, effectively remove the phenomena of offset abrasion and gnawing, and make the tire wearing even.

Mechanical Suspension Note ( Just for Reference):

1.Can be asked to choose a balance arm pin,50,60 or 70

2.May need to select side wall thickness 6mm , 8mm or 10mm

3.Spring specification:width 90mm,100,120mm ;the quantity of leaves is optional

4. A :Empty load size ,B: Full load size

Mechanical Suspension Detail Photos:
