Help CenterChina ISO Landing Gear 28T Professional Manufacturer of Jost Landing Gear
Related Products
-
Outside Gear Holland Type 28T Landing Gear for Truck TrailerUS$ 120 - 160MOQ: 10 Pairs -
Outside Gear Holland Type 28T Holland Type Semi-trailer Landing GearUS$ 120 - 160MOQ: 10 Pairs
-
Outside Gear Holland Type Holland Type Landing Gear T ShoeUS$ 120 - 160MOQ: 10 Pairs
-
Outside Gear Holland Type 28T Holland TypeTrailer Parts Landing GearUS$ 130 - 150MOQ: 10 Pairs
-
28T High Quality Landing Gear for Semi TrailerUS$ 120 - 160MOQ: 10 Pairs
Professional Manufacturer of Jost Landing Gear Information: |
Dimention of LGH28-A0101T: |
Landing Leg Capacity: 28T |
Static Load: 80T |
Speed: Higher 9, Lower 0.9 |
Lift/Height: 430/830; 480/8480 |
Wondee Autoparts Landing Gear Factory supplies landing foot for semi-trailers & RV semi-trailers. |
Jost Landing Leg Box: Inside & Outside |
Operation: Single side & Double side |
Lifting Capacity: 25 ton ~ 35 ton. |
Static Load: 50 ton ~ 90ton |
Gear Food Type: T, A, S, G, R |
Out put: 80,000 pairs yearly |
Manufacturer of Jost Landing Gear Dimension: |
Number | Capacity | Static Load | Speed | Lift | Height | |
kg | kg | Higher | Lower | mm | mm | |
LGJ28-B0201T | 28000 | 80000 | 9 | 0.9 | 430 | 830 |
LGJ28-B0202T | 28000 | 80000 | 9 | 0.9 | 480 | 880 |
Professional Manufacturer of Jost Landing Gear Specifications ( Just for Reference ): |
Reliable, high-quality seal keeps water out and extends life |
Unique tapered backplate for enhanced durability |
Gearbox with low-temperature premium lube provides easy cranking and reduces component wear; protection from -65ºF to 225ºF |
Low Speed Gear - 38.6 turns per inch |
High Speed Gear - 4.5 turns per inch |
Massive, 5-inch upper housing with 80,000 psi minimum yield and retractable tube; maintains strength while saving weight. Lower leg is 12% larger than standard-duty landing gear |
Three-gear train gearbox with exclusive Man-Saver gear ratios handles normal loads with 40% less effort |
Exceeds all AAR M-931 and all TTMA RP-4 performance specifications. |
Includes an industry leading 5-year warranty |
Jost Landing Gear Function & Attention ( Just for Reference ) : |
1.The device is use for semi-trailer and special trailers. |
2.It lift and support trailer when it is separated from tractor. |
3.It's also in use for all sorts of trucks that they are secured to work as jack. |
4.The quality is up to the standard of American ABS specification. |
5.Landing Gear has slow and fast two speed. Please use slow speed when loading. It is easy to operate. Do not use fast speed. It is possible to injure landing gear. |
Manufacturer of Jost Landing Gear Payment & Terms: |
MOQ: 10 Pairs |
FOB Price: 120 ~ ~ 160 USD Per Pair |
Payment Terms: L/C, T/T, Western Union |
Supply Capacity: 2000 Pairs per Month |
Delivery Time: About 20 Working Days |
Delivery Port: Qingdao, Xiamen |
Package: By Pallet; By Wooden Case; 200 Pairs in 1X20FCL. |
Professional Manufacturer of Jost Landing Gear Drawings ( Just for Reference ) : |
The Detail Photos about Professional Manufacturer of Jost Landing Gear:
Besides Manufacturer of Jost Landing Gear, WONDEE AUTOPARTS also Supply LEAF SPRING,SEMI TRAILER, WHEEL RIM,LANDING GEAR,SUSPENSION ... .... ...
