China High Quality Fuwa 13T Light Trailer Axles

Light Trailer Axles Information:

Product Name: China High Quality Fuwa 13T Light Trailer Axles

We can supply various kinds of auto axles for buses, trucks, agriculture vehicles, engineering

construction and semi-trailers, including steering axles, driving axlesand semi-trailer rear axles.

The designated productive capacity of is 50,000 pieces per year.

(1)Drum, Brake Lining 420x180mm, Track TR 1820mm

(2)Unique one-piece, special heat-treated, low-alloy steel axle beam

(3)greater capacity, superior fatigue capability

(4)more stability, greater capacity and lighter weight

(5)Package: By Pallet; 58 Pieces in 1*20FCL.

Light Trailer Axles Features:

1.Axle beam use 20Mn2 seamless pipe, through one-piece press forging and special heat-treatment,

which has great over loading capacity and high intensity.

2.Axle spindle,which was processed by digital controlled lathe, is made of alloy material. The bearing position is

processed by the method of hardending operation,therefore the bearing can be fixed by hand instead of heating,

also convenient for maintain and fixing.

3.Axle spindle is connected by the by submerged arc welding, which make the whole beam more reliable and solid.

4.Axle bearing position is used the grinding machine to keep the bearing at the same level, after processing, it can

assure that the concentricity within 0.02mm strictly.

5.Axle grease lubricant is supplied by EXXON Mobile which could providehigh lubricating performance and

protect bearing well.

6. Axle brake lining is high performance, non-asbestos, non pollution and long service life.To make check and

replace easily, also come with the position of the exhaustion to remind customer to check and maintain.

7.Axle bearing is adopted famous brand in China, with the advantages of over loading capability,

High rotating speed, good intensity, abrade resistant and heat resistant.

Light Trailer Axles Dimension:

Part No.

Max.                 Capacity

Distance         of Chamber

Track

Axle Beam

Brake size

Length

Bearing

Weight

XDF13-01

13

388

1840

150*150

420*180

2196

518410/45-518410/45

420

XDF15-02

15

396

1850

150*150

420*180

2185

518410/45-220110/49

383

XDF16-02

16

354

1850

150*150

420*220

2218

518410/45-220110/49

425
