Specifications
Diesel engineThe diesel engine could be used in most agricultural equipment,such as power tiller,water pump,sprayer and so on.
QG for better life
CP170F
This kind of 5HP diesel engine is popular in the market for it's good quality and competitive price.QG diesel engine widely used in farm equipment such as:mini power tiller,water pump,generator etc.
*The reason why customers choose QG diesel engine:
- Our factory are reliable and sincerity;
- Our engine is in good quality and has CE,ISO9001,TUV certification;
- We have strict quality control system,so customers never need to worry the quality;
- The engine could be started by hand or electric,that's depends on customers preference;
- The engine is easy start and it's energy saving.
* Detail data of the diesel engine:
| MODEL: | CP188F (10HP) | CP186F(9HP) | CP178F(6HP) | CP170F(5HP) | CP173F(5.5HP) |
| Engine Type: | Singel-cylinder,vertical,4-stroke,air-cooled diesel engine | ||||
| Combusion system | Direct injection | ||||
| Bore×Stroke(mm): | 88*75 | 86*72 | 78*62 | 70*55 | 70*55 |
| Displacement(cc) | 456 | 418 | 296 | 211 | 211 |
| Rated speed | 3600 | ||||
| Max output(kW/hp) | 8/11 | 6.3/9 | 4.0/5.5 | 3.6/5 | 4.5/6.5 |
| Starting system | Recoil/Electric | ||||
| Rotary direction of output axis | Left | ||||
| Fuel grade | 0# diesel fuel(summer); 10# diesel fuel (winter) | ||||
| Fuel Capacity(L) | 5.5 | 5.5 | 3.5 | 2.5 | 2.5 |
| Lubrication | |||||
| Lubrication capacity(L) | 1.65 | 1.65 | 1.1 | 0.75 | 0.75 |
| Net weight(kg) | 48/50 | 48/50 | 33/35 | 27 | 27 |
| Overall dimensions | 520*450*560 | 520*450*560 | 480*430*520 | 332*376*415 | 335*386*425 |
| (L×W×H)(mm): | |||||
*Products pictures of the diesel engine:
Delivery time:We will delivery the goods within 10 days after finished the production,
Packaging detail:1 set/Carton with original seaworthy packing.
*About our company:
QG Tiller Manufacturing Ltd was established in 2009 and located in Chongqing, along with the Yangzi river. As a professional power tiller manufacturer, QG own a batch of well trained personnel to support it. After the effort of whole staff, now we have 3 centers: R&D center, Production center and the Marketing center. It means we design, produce and sell the tillers by ourselves.
Moreover, we have 2 factories, one is for power tiller and other farm machines, the other one is special for the gears and gearbox. We have more than 10 years experience on the gear and gearbox production, we not only use them on our machines, but also supply for other companies. For the automobile gear, we are the supplier of Chang'an, Bentz, etc. Thus, it makes our power tillers more competitive in the price and quality.
Because of the market-oriented policy, we always put the customer needs on the first place. we are happy to customize the special products according to the real demands. Also we are designing and introducing the new products: Generators, water pumps, engines, sprayers to meet the market demands.
Your satisfaction is what we always strive for, come to us we will show you our profession.
1. Are you Factory, and where is it?
QG: Yes. Our factory is located in Chongqing, along with Yangzi river. Welcome to visit.
2. What's your daily output?
QG: 300 sets/ day. If you need urgently, the trained workers of the joint company will help out.
3. Is sample available? And how about the delivery?
QG: Yes sample is available, 5-7 days will be shipped out after the order confirmed. For big order, it takes 10-15 days usually.
4. What is the MOQ?
QG: We suggest 1 20" container for shipping cost saving, but small order is also ok.
5. What is the warranty?
QG: 12 months warranty for whole product, except the quick-wear part.
...................................................................................................................
