high speed low noise skateboard/slide plate roller bearing
- 100000 Piece / Pieces per Month
- Guangzhou
- T/T L/C D/P D/A Credit Card PayPal
- 2017 new toy magic cube stress relief plastic fidget cube
- Roller Chains 10B-2 Duplex Roller Chains and Bushing Chains Bike/Bycicle/Motorcycle Chain
- Stainless Steel 304 Roller Chains B Series 40B-1 Simplex Roller Chains and Bushing Chains
- Roller Chains B Series 20B-2 Duplex Roller Chains and Bushing Chains Bike/Bycicle/Motorcycle Chain
- Precision SS Roller Chains B Series 16B-1 Simplex Roller Chains and Bushing Chains Bike/Bycicle/Motorcycle Chain
- SS Roller Chains B Series 12B-1 Simplex Roller Chains and Bushing Chains Bike/Bycicle/Motorcycle Chain
Product Details
Brand Name: | YCZCO | Bore Size: | 8, | Outside Diameter: | 22, |
Model Number: | 608-28 | Precision Rating: | ABEC-1.3.5.7.9 | Seals Type: | ZZ |
Number of Row: | Single Row | Place of Origin: | Fujian, China |
Product Description
1.Product detail
Deep groove ball bearing | ||||||||
Brand | YCZCO | Item No. | 608-28 | |||||
Name | high speed low noise skateboard/slide plate roller bearing | |||||||
Model | deep groove ball bearing | |||||||
Material | Carbon steel/stainless steel/bearing steel etc | |||||||
Precision | ABEC-1, ABEC-3, ABEC-5, ABEC-7 | |||||||
Bore Size | 8mm | Outside diameter | 22mm | Width | 7mm | |||
Clearance | Co,C1, C2, C3, C4 | |||||||
Cage Type | Steel/rubber | |||||||
Seals Type | Plastice/steel/Open | |||||||
Features | They can sustain radial loads mainly and can also sustain some axial load in either direction. The bearings have low friction and very little noise or vibration, These characteristics make them to be available for situations of high speed, high precision, low friction and low noise operations. | |||||||
Application | Deep groove ball bearings can be used in high-speed, high precision applications for: sliding door /window ,toys,furniture and so on. | |||||||
Package | industrial package or as customers' requirement | |||||||
Price | FOB, price | Delivery Time | About 30 working days |
2.About the material
Carbon steel is steel in which the main interstitial alloying constituent
is carbon in the range of 0.12–2.0%. The American Iron and Steel Institute
(AISI) defines carbon steel as the following: "Steel is considered to be carbon
steel when no minimum content is specified or required for chromium, cobalt,molybdenum, nickel, niobium, titanium, tungsten, vanadium or zirconium,
or any other element to be added to obtain a desired alloying effect; when the
specified minimum for copper does not exceed 0.40 percent; or when the
maximum content specified for any of the following elements does not exceed
the percentages noted: manganese 1.65, silicon 0.60, copper 0.60.
Stainless steel is the universal name for a number of different steels used primarily for their anti-corrosive element. Stainless steel has been developed to
resist a number of corrosive environments. It ensures that our workplaces are
safe,that buildings last longer and that our food preparation surfaces are hygienic.
It is also an earth friendly material; it can be melted down, recycled and made into something else.
3.How to choose bearings?
Usually these factors should be considered: the bearing size and direction
of the load, the nature of the bearing load, self-aligning performance requirements, bearing rigid requirements, bearing performance requirements, the speed of the bearing working environment temperature requirements and some other aspects
such as the requirement of bearing axial winding, restrictions on the size of bearing appearance, installation and dismantling is convenient, the requirement of the
bearing seal and the friction torque, vibration and noise, etc
4.Our service
Customer service | Any question will be welcome ,we will answer you asap . |
Lead time | 1.Sample lead time:7-15 working days 2.Order lead time:45 working days(sample avaliable) |
Transit time | 1.Express:DHL,FedEX,UPS 2.By sea: required shipping company or by us 15 days or more |
Receiver’s signature | If you find the receipt is not intact, please contact us |
After-sale service | If you find the product is abnormal, contact us and we will try to solve it |
Other service
| Material and color can be free to choose (option: POM, nylon, glass fiber, etc) OEM offered for injection molding roller and non-standard bearing |
5.Packaging&Shipment
Packaging
1)industrial packaging :Plastic bag > Paper carton
Poly tube >Wooden Pallet
2)as customer requirement
Our packing is strong enough and safe for transport and shipment.
Shipment
Transportation of goods may take place by road railwayair or combined
ways, etc. The mode of transportation depends on you as long as it is
convenient for you.
6.Our craft:
Heat treatment:Bearing under heat treatment can greatly improve its life, reliability, rigidity, wear resistance and anti-fatigue function.Its expected range
of the ring can be extrend to 28mm.
Precision Grinding:The good grinding processing in the outer and
inner ring, make the surface smooth and delicate, grinding crack and groove
error obviously reduced and touch surface larger.
7.About us
Welcome to contact us:
Thank you very much!!!
Contact Us
- Fuan City Yuan Cheng Bearing Co., Ltd.
- Contact namejulie Huang
- Phone86-757-85610506
- AddressNo.8 Shantang Industrial Zone,Hecun, Lishui Town, Nanhai District,Foshan City, GD Pro. Foshan,Guangdong
