WH-C330 Reversible Vibratory Hand Compactor
- 2000 Piece / Pieces per Month
- shanghai
- T/T
You May Like
Product Details
| Condition | New | Application | Widely used in construction size,civil work and etc | |
| Power Type | Gasoline | Brand Name | W&H Vibratory Hand Compactor | |
| Model Number | WH-C330 Vibratory Hand Compactor | Place of Origin | Jiangsu, China | |
| Power(W) | 13HP/9HP | Dimension(L*W*H) | 100*60*115cm | |
| Weight | 251kg | Certification | CE/SGS/BV/ISO | |
| Warranty | one year |
Product Description
Specifications
WH-C330 Reversible Vibratory Hand Compactor1.Fast leveling speed
2.High quality and low price .
3.open design reduces dirt.
WH-C330 Vibratory Hand Compactor
Features of Vibratory Hand Compactor :
1. Large shock mounts reduce vibration to the handle.
2. Heavy-duty shock mounts reduce vibration to the upper deck.
3. Wear-resistant base plates extend life, open design reduces dirt building.
4. Centrally-located lifting bar allows easy transportation in and out of trenches.
5. Semi-covered protection cage protects the plate from accidental job-site damage;
Spetification of Vibratory Hand Compactor :
Model | WH-C330H | WH-C330HC | WH-C330D |
Engine type | air-cooled single cylinder 4-stroke | ||
Engine | Honda GX390 | WH188F | Diesel WH186F(E) |
Size of base plate(L*W) (cm) | 83.5*67 | ||
Compaction depth(soil)(cm) | 80 | ||
Centrifugal force(KN) | 38 | ||
Operating weight (kg) | 233 | ||
Shipping weight (kg) | 251 | ||
Shipping size(L*W*H)(cm) | 100*66*115 | ||
Photos and Certificates of Vibratory Hand Compactor :
