Specifications
WH-Q500 concrete cutting machine1.rustless water tank provides an optimum flow and volume of water to the blade
Concrete Cutting Machine WH-Q500
Concrete Cutting machine Features
1. Smooth cutting and directional stability is achieved due to the optimum position of the machines center of gravity.
2. Ergonomically designed, height adjustable handles with comfortable grips.
3. Hinged front, lift-up blade guard is designed to provide easy blade replacement.
4. Rustless water tank provides an optimum flow and volume of water to the blade.
5. The elevation equipment is manually locked which will make the depth of edge consistent.
6. Throttle control as standard part.
Concrete Cutting Machine Specification:
Model | WH-Q450H | WH-Q450R | WH-Q450D | WH-Q500H | WH-Q500D | |
Engine type | Air-cooled, single cylinder,4-stroke | |||||
Engine | Honda GX390 | Robin EY28 | Diesel, WH186F | Honda GX390 | Diesel, WH186F | |
Power(Hp) | 13.0 | 7.5 | 9.0 | 13.0 | 9.0 | |
Operation Weight (kg) | 108 | 108 | 108 | 110 | 110 | |
Max, cutting depth(cm) | 16 | 18 | ||||
Driving mode | Manual push | |||||
Water tank capacity(L) | 30 | 30 | ||||
Blade Size (cm) | 40.0-45.0 | 40.0-50.0 | ||||
Package size(L*W*H)(cm) | 95*58.5*107 | 95*58.5*108 | ||||
