Home > Manufacturing & Processing Machinery > Engineering & Construction Machinery > Engineering & Construction Machinery Parts > OMP Best Combination Orbit Hydraulic Spool Valve Motors

OMP Best Combination Orbit Hydraulic Spool Valve Motors

Name: OMP Best Combination Orbit Hydraulic Spool Valve Motors
Brand: KERSEN
SKU: 140154894
Availability: InStock

OMP Best Combination Orbit Hydraulic Spool Valve Motors thumbnail-1

OMP Best Combination Orbit Hydraulic Spool Valve Motors photo-1

US$ 50 - 60 MOQ: 1 Piece

Key Specifications

Get Latest Price

Type:

Hydraulic Motors

Model Number:

OMP series

Brand Name:

KERSEN

Contact Supplier Request Quote Chat Now

Jining Kersen Hydraulic Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao or Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Type Hydraulic Motors

Model Number OMP series

Brand Name KERSEN

Place of Origin Shandong, China

OMP Best Combination Orbit Hydraulic Spool Valve Motors

Product Description

Introduction

Kersen can offer full ranges of hydraulic motor, such as: OMP, OMPS, OMR, OMRS, OMRSW OMW, OMH, OMS, OMV, OMV and 4000 series. Now we also have brake motor , totally 4 types , OMS brake , OMT brake and OMV brake, and VM 40 motors.
The motors are low speed and high torque.
The motors have been extensively used in metal cutting machines, wood working machines, agriculture and forestry machinery, engineering machinery , plastic injection machinery, mining equipment, fishing equipments, cleaning machine and drilling equipments etc .
Our products has gained ISO 9001 quality certificate , and our domestic bigger customer includes XCMG etc . And we oversea customers more than 50 countries .
Welcome to contact with us for specific information of the motors .

Disp. cc/r		50	63	80	100	125	160	200	250	305	370	395
Flow	Rated	38	53	53	53	53	53	53	53	53	53	53
LPM	Max	45	57	57	57	57	57	57	57	57	57	57
Speed	Rated	750	778	635	510	430	329	266	213	171	142	133
RPM	Max	875	832	680	537	420	374	281	226	182	150	141
Pressure	Rated	138	138	138	138	138	124	124	124	103	90	90
Bar	Max	155	155	155	155	155	138	138	138	124	103	103
Touqur	Rated	92	121	150	196	230	271	328	401	417	402	429
Nm	Max	105	137	174	213	256	297	358	410	441	460	458
weight(Kg)		6.3	6.7	7.0	7.5	7.6	7.7	8.0	8.4	8.8	9.4	9.6

Feature

Compact in design with spool valving and Geroler
Imported high pressure capacity shaft seal
Design and manufacture of the spline and drives give the motor durability
Wide variety of mounting flanges,shafts,ports and speed provides design flexibility
Direction of shaft rotation and speed can be controlled easily and smoothly
Best combination of high efficiency and economy in medium duty applications

Advantages

50cc/63cc/80cc/100cc/125cc/160cc/200cc/250cc/305cc/370cc/395cc
Unaided shaft with roll gear set design and high-efficiency
Special dynamic seal can bear high back pressure
Variety mounting of flange, output shaft and port
Small volume and smart structure
Widely used at plastic injection machinery and agriculture machinery machine

Pictures

Certificate

Packaging & Shipping

Trade

OEM	Yes
MOQ	1 PCS Steering Control Unit
Port	Qingdao, Shanghai
Lead Time	Sample	Within 7 working days
	Steering Control Unit	15-20 working days
Payment	L/C,T/T
	30% advance payment, the balance paid before shipment
Packing	Motor each have their own carton, the outer packing is a five-layer plywood boxes
Shipping	1)By air or sea or combined transportation. 2)Express: FEDEX, UPS, DHL, EMS.

In general, we deliver goods 15-20 days after the account’s reaching, and we usually choose DHL, UPS, TNT, EMS or Fed-Ex, of course, you can appoint another .
