AS500 4WD 50HP Mini Articulated Backhoe Loader Used A/C
US$ 13,500 - 15,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
ANSION
Model Number:
AS500
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Port China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
AS790 Towable Backhoe for Sale Small Tractors YUCHAI ENGINE 83kW ACjoystick for Ps2 Pilot JoystickUS$ 25,000 - 25,000MOQ: 1 Set -
AS790 Towable Backhoe for Sale Small Tractors YUCHAI ENGINE 83kW AC Pilot JoystickUS$ 25,000 - 25,000MOQ: 1 Set
-
AS790 Backhoe for Sale 1.2CBM YUCHAI ENGINE 83kW AC Pilot JoystickUS$ 25,000 - 25,000MOQ: 1 Set
-
8ton 3CX Backhoe Loader Dubai Original Manufacturer With Deutz Engine and Carraro Electric TransmissionUS$ 33,000 - 39,000MOQ: 1 Set
-
AS790 Backhoe for Sale 7.9ton 1.2CBM YUCHAI ENGINE 83kW AC Pilot JoystickUS$ 25,000 - 25,000MOQ: 1 Set
Condition
New
Brand Name
ANSION
Model Number
AS500
Place of Origin
Shandong, China
Type
Backhoe Loader
Moving Type
Wheel Loader
Dimension(Long * Breadth * High)
5100*1980*2900 mm
Rated Load
1600 kg
Certification
ISO9001
Warranty
12 months
After-sales Service Provided
Engineers available to service machinery overseas
ANSION 4WD 5TON Backhoe Loader AS500 (Single joystick pilot control)
Main Specification
Total Length |
mm |
5100 |
|
Total Height |
mm |
2900 |
|
Total Width |
mm |
1960 |
|
Total Operating Weight |
kg |
5400 |
|
|
Backhoe Parameter
|
Rated Backhoe Bucket Capacity |
m3 |
0.2 |
Max. Digging Depth |
mm |
3400 |
|
Max. Digging Height |
mm |
5000 |
|
Max. Digging Radius |
mm |
4600 |
|
Turning Angle of Movable Arm |
° |
180 |
|
|
Loading Parameter
|
Rise Height |
mm |
3700 |
Discharge Height |
mm |
2700 |
|
Min. Turning Radius |
mm |
4800 |
|
Discharge Distance |
mm |
1000 |
|
Rated bucket capacity |
M3 |
0.8 |
|
Rated Loading Weight |
kg |
1600 |
|
Rise Time of Movable Arm |
s |
3.5 |
|
Fall Time of Movable Arm |
s |
2.5 |
|
Comprehensive Time |
s |
7 |
|
Engine Model |
Xinchai |
||
Rated Power of Engine |
KW |
36.8 |
|
Work Pressure |
Mpa |
16~18 |
|
Max. Grade Ability |
% |
25 |
|
Walking Speed |
km/h |
18~28 |
|
Min. Ground Clearance |
mm |
260 |
|
Wheel Base |
mm |
2000 |
|
Tread |
mm |
1530 |
|
Tire model |
mm |
20.5-16 |
|
Real Picutres Show
