Solar High Power Deep Well Stainless Pump

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Port Qingdao
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China		Brand Name	XINWAN
Model Number	STP20

Product Description

*Ideal for waterfall,water feature,cascade fountain,pond filtration
*Brushless,dry run & locked rotor protected
*Solar powered

•Typical applications include pumping water for waterfall and water features as well as conducting pond water filtration.

•The solar powered water pump kit consists of a DC brushless dry run protection water pump and a solar panel module.

•Solar energized, maintenance free, operation cost free, green and easy to install with no wiring work needed. More importantly, it is much safer for kids due to its low working voltage.

•Self-developed unique dry run protection technology prevents the pump from burning out when fountain or pool dries out.

•Locked rotor protection prevents the pump from possible failure when pond debris blocks the pump.

•Brushless motor with no failure-prone carbon brush or shaft seal so that a robust and long service life could be expected.

•Ceramic shaft, runs steadily and quietly.

•Rohs and CE certified, safe and green.

•Designed and manufactured to have high power efficiency.

•Cost-effectiveness, competitive price.

Item No.		SP25-801210D
Description		Solar brushless water pump kit
Category		Solar pump kit

Product Summary
Solar panel		Peak power				25W
		Max-power voltage				17.28V
		Max-power current				1.447A
		Installation method				plastic ground spike
Pump		Pump item				BP801210D
		Max. head				2.1m (6.9ft)
		Max. flow rate				2480L/H (647.4GPH)
		Cable length				5m (16.4ft)
		Nozzle item				N/A
Flow adjustable						No
Dry run protection						Yes
Individual box size (cm)						643725
Individual box G.W (kg)						7.5
Master carton size (cm)						643725
Quantity per carton (pcs)						1
Master carton G.W (kg)						7.5
Min. order quantity (pcs)						200
Quantity per 20' (pcs)						378
Quantity per 40’ (pcs)						798
Warranty						3years

Litres per hour - At various pumping heights (Head)
Operating voltage	@ 0m	@0.5m	@0.75m	@1.0m	@1.5m	@2.0m	@2.5m	@3.0m	Max height
18V	2480	2180	1890	1520	1090	180	0		2.1m

Pump Curve
