Electric Start LHW-101 2WD 12HP Hand Tractor
Brief
Weifang LuHe Wang hand tractor is dual-function product that can be operated as the towing machine as well as driving machine. It has small and compact structure, light weight,reliable performance,long service life, easy operation and good running ability,also they are be assemble a seating equipment for driver.
The hnd tractor is suitable for working in paddy field, dry field, orchard, greenhouse, hilly field. With matched accessories and farm implement, they can be used for ploughing,harrowing,seeding, cultivating, harvesting, drilling, ditching, transporting, irrigating, sprinkling, spraying, threshing,milling,and so on.
Specification
Weifang LuHe Wang Hand Tractor | ||||||||
Model | LHW-101 | |||||||
Overall Dimension (mm) | 2120×840×1160 | |||||||
Ground Clearance (mm) | 210 | |||||||
Wheelbase(mm) | 680~740 | |||||||
Weight (kg) | 260 | |||||||
Semi-axis (cm) | 340 | |||||||
Weight in use(with oil , water, tools) (kg) | 350 | |||||||
Tyre Model | 6.00~12 | |||||||
Tyre Pressure | Field Work | 100~120(1.0~1.2kgf/square centimeter) | ||||||
Transportation Work | 180~200(1.8~2.0kgf/square centimeter) | |||||||
Engine | Power | 12HP/8.8KW/2000rpm | ||||||
Type | Vertical, One Cylinder, Four Stroke, Diesel powered, Water-cooled | |||||||
Gear | 1 | 2 | 3 | 4 | 5 | 6 | Reverse1 | Reverse2 |
Speed(km/h) | 1.68 | 2.61 | 4.22 | 6.79 | 10.57 | 17.08 | 1.29 | 5.22 |
Traction(N) | 1800 | 1800 | 1800 | 1800 | 1800 | 1800 | _ | _ |
1. 18 months warranty since machine arrives destination port
2. The spare parts:
(1) We will send you the tool box for free.
(2) For the vulnerable parts, we can send you for free, During the warranty, owing to the quality problem, we will send the replacement for free.
3. T/T (Telegraphic transfer) payment: 30% as deposit, 70% balance payment shall be paid before delivery
4. delivery time: 20 working days after confirmation of deposit
5. Loading: LCL in iron crate or wooden case
Details
We are the specialized manufacturer for hand tractor for decades in Weifang City.
In total,4 production line in our factory,LHW-101,LHW-61,LHW-91,LHW-121,from 6HP to 20HP.
Many different configuration hand tractors can be chosen.
We also supply OEM service.
we would like to supply the suitable tractors according to your detailed requirement.
Various type of farm implements for selling:
Welcome your enquiry for our hand tractors,
we would like to try our best to help you to choose the suitable type!
