2017 year factory sales 24 hp farm mini tractor,electric start mini tractor
- 5000 Set / Sets per Month
- QINGDAO
- T/T
You May Like
-
12 HP 15 HP Mini Tractor / mini farm tractor with implements
-
2017 Hot-selling mini farm tractor for Russia
-
15hp 2wd electric start mini tractor
-
factory sales green color 24 hp farm mini tractor with awning
-
24 hp green color electric start diesel engine farm tractor
-
15 hp multi-purpose farm mini tractor for sales
Product Details
Condition | New | Type | Walking Tractor | |
By wheel | 2WD | Usage | Farm Tractor | |
Drive Type | Gear Drive | Power(W) | 8820 | |
Certificate | Other, ISO | Brand Name | LHW | |
Model Number | LHW-12 | Place of Origin | Shandong, China | |
After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
1.Specification request factory sales 24 hp farm mini tractor,electric start mini tractor | ||
Overall tractor | Model | LHW-New Type |
Transmission box: | Special steel casting transmission:20CrMnTi | |
Main dimension(mm): | LxWxH=(2400X1300X1320) | |
Wheelbase:(mm) | Frant:1050mm;Raer:980mm | |
front wheel(mm) | 550mm | |
Rear-wheel(mm) | 750mm | |
Mini-turning circus radius:(m) | 2.8m | |
Structural weight:(kg) | 540kg | |
speed:km/h | Forward speed | 1.73,3.42,5.71,8.01,15.80,26.40 |
Reverse speed | 1.37,6.35 | |
Engine | Engine model: | Diesel Engine |
Fuel consumption per hour: | 1.0L~1.5 L | |
Rated turning speed: | r/min 2400 | |
Rated power: | 20HP 24HP | |
Cooling type: | Evaporative cooling, Condense | |
Drive system | Clutch | Dry type |
Final drive: | Single stage spur gear transmission | |
Differential: | Support conical planetary gear reducer | |
Transmission: | (3+1)*2 cylinder gear drive | |
Brake: | External shoe type brake | |
Drive type between engine and clutch: | Triangle belt | |
Drive type between PTO and hydraulic pump : | V-belt | |
Travel and turning system | Front axle: | Adjustable separating type |
Front wheel | Front wheel 5.0-12 | |
Rear-wheel | Rear-wheel 7.50-16 | |
Tyre size and pressure of front wheel | Front wheel: 600kpa | |
Tyre size and pressure of Rear-wheel | Rear-wheel: 250kpa | |
Steering gear: | Worming gear type | |
Toe-in of front wheel(mm): | 4~8 | |
Front-wheel camber: | 20±30’ | |
King pin inclination: | 70±15’ | |
Kingpin caster: | 30±15’ |
All the under implements could be matched with our 2017 year factory sales
24 hp farm mini tractor,electric start mini tractor,electric start mini tractor,
more information,such as overall dimensions and so on.
Please contact us without hesitation.
1.)In bulk or package with plywood box;
2.)Transportation:by ship,by air or by train.
All according to you request.
1.) Weifang Guihua Agricultural Equipment Co., Ltd. which near to qingdao port have been in the
indurtry of walking tractor , farm tractor and its accesorry for 10 years yet ,and daily output
more than 300sets.
2.) We strictly control the process of manufacturing form materials to finished products.
3.) Our main market is : vietnam , Russia , Ukraine and so on
Welcome to weifang , Shandong , China , welcome to our company !
1) MOQ for 2017 year hot sales new type 24 hp multi-purpose farm mini tractor,electric start mini tractor
1 UNIT
2) Spare Parts
The Easy damage parts will be sent you together with the tractor. And in warranty period,
if the spare part is not work ,because of the quality, new parts will be sent to you for free
3) Shippment
We can help you arrange shippment
4) Delivery Time
One container:15-30 days.
5) Warranty Time
Completes service system, one year since arrival of destination port.
6) Payment Terms
T/T , 30 % as advance deposit ,70% balance against after received the copy of B/L ; L/C
7) Tractor Logo
We have our own logo, and we also can make your own logo in your order for free
8) Package and loading quantities
Nude Package:50 sets/40 HQ for mini tractor, 95 sets /40 HQ for walking tractor.
9) Implements
Mower, Plough, Trailer, Rotary tiller, or as your requirements.
10) Parts Supply
Complete parts Workshop, and can supply all parts.
For More Details, Pls Kindly Contact Me and I Will Answer You Within 24 hours!
