1.Specification request for 24 hp farm tractor for sales | ||
Overall tractor |
Model |
LHW-New Type |
Transmission box: |
Special steel casting transmission:20CrMnTi |
|
Main dimension(mm): |
LxWxH=(2400X1300X1320) |
|
Wheelbase:(mm) |
Frant:1050mm;Raer:980mm |
|
front wheel(mm) |
550mm |
|
Rear-wheel(mm) |
750mm |
|
Mini-turning circus radius:(m) |
2.8m |
|
Structural weight:(kg) |
540kg |
|
speed:km/h |
Forward speed |
1.73,3.42,5.71,8.01,15.80,26.40 |
Reverse speed |
1.37,6.35 |
|
Engine |
Engine model: |
Diesel Engine |
Fuel consumption per hour: |
1.0L~1.5 L |
|
Rated turning speed: |
r/min 2400 |
|
Rated power: |
20HP 24HP |
|
Cooling type: |
Evaporative cooling, Condense |
|
Drive system |
Clutch |
Dry type |
Final drive: |
Single stage spur gear transmission |
|
Differential: |
Support conical planetary gear reducer |
|
Transmission: |
(3+1)*2 cylinder gear drive |
|
Brake: |
External shoe type brake |
|
Drive type between engine and clutch: |
Triangle belt |
|
Drive type between PTO and hydraulic pump : |
V-belt |
|
Travel and turning system |
Front axle: |
Adjustable separating type |
Front wheel |
Front wheel 5.0-12 |
|
Rear-wheel |
Rear-wheel 7.50-16 |
|
Tyre size and pressure of front wheel |
Front wheel: 600kpa |
|
Tyre size and pressure of Rear-wheel |
Rear-wheel: 250kpa |
|
Steering gear: |
Worming gear type |
|
Toe-in of front wheel(mm): |
4~8 |
|
Front-wheel camber: |
20±30’ |
|
King pin inclination: |
70±15’ |
|
Kingpin caster: |
30±15’ |
|
This kind of mini tractor is a multipurpose mini tractor which could be matched with
various accessories (such as the follows picture showing),implement the functions of
sow,cultivated land, plough, mowing the lawn,and so on.It's high power and low
consumption characteristics was deeply loved by the masses of customers.
1) MOQ
1 UNIT
2) Spare Parts
The Easy damage parts will be sent you together with the tractor. And in warranty period, if the spare part is not
work because of the quality, new parts will be sent to you for free
3) Shippment
We can help you arrange shippment
4) Delivery Time
One container:15-30 days.
5) Warranty Time
Completes service system, one year since arrival of destination port.
6) Payment Terms
T/T , 30 % as advance deposit ,70% balance against after received the copy of B/L ; L/C
7) Tractor Logo
We have our own logo, and we also can make your own logo in your order for free
8) Package and loading quantities
Nude Package:50 sets/40 HQ for mini tractor, 95 sets /40 HQ for walking tractor.
9) Implements
Mower, Plough, Trailer, Rotary tiller, or as your requirements.
10) Parts Supply
Complete parts Workshop, and can supply all parts.
For More Details, Pls Kindly Contact Me and I Will Answer You Within 24 hours!
1.) Weifang Guihua Agricultural Equipment Co., Ltd. which near to qingdao port have been
in the indurtry of walking tractor , farm tractor and its accesorry for 10 years yet ,
and daily output more than 300sets.
2.) We strictly control the process of manufacturing form materials to finished products.
3.) Our main market is : vietnam , Russia , Ukraine and so on
Welcome to weifang,Shandong,China.Welcome to our company !
Any needs,pls contact me without hesitation!
