Home > Products > New Products > iso ASTM YT YG YW K10 K20 K30 M05 M10 M20 M30 P10 P20 P30 P40 cemented tungsten carbide straight round square bar in stock
iso ASTM YT YG YW K10 K20 K30 M05 M10 M20 M30 P10 P20 P30 P40 cemented tungsten carbide straight round square bar in stock
- 3000000 Piece / Pieces per Month
- Shanghai/Shenzhen/Guangzhou/Dalian/Tianjin
- T/T D/P D/A Credit Card PayPal
- CD-650 High Precision Tungsten Carbide Blank for Carbide Punches Die Inserts
- Yg20c Tungsten Carbide Metal Forming Dies for Cold-Forming Screws Bolts and Rivets
- Bk15/Bk20 Customizable Tungsten Carbide Seaming Roller Dies for Can Sealing Side
- YG25/GT55 tungtsen carbide punching dies for bolt
- K10/K20 Tungsten Carbide Valve Ball with Hollow Hole for Valve Pumps
- Original Material Tungsten Carbide Inlet Seats for Air-Operated Airless Spray Pumps
Product Details
Brand Name: | Santon, Santon | Model Number: | tungsten carbide | Alloy Specification: | ISO |
Particle: | many size |
Product Description
Type
Many Types are available,please feel free to contac us to get more detail..
Our Service
1. We not only provide standard parts but also OEM service.
Please feel free to connect us all the time 24/7.
2. Our experienced technican and enthusiastic service will keep you free from worry.
3. The completely production line from raw material to delivery,all links are
under our control.
Our advantages:
1. Made from 100% virgin raw material.
2. Products with advanced equipment and perfect workmanship.
3. All products go through in-process and final inspection.
4. Stable and continuous production ability.
5. We produce tungsten carbide plate in various size,grades and surface
conditions.the product can also be customized by customer's design.
6. All products must be inspected strictly and only those with out any
harm can be shipped out.
7. We located in Chengdu International Airport(less than 0.5 hour'sdrive),
so it will be very convenient for our overseas customers' on-site
visit if requred,which also guaranteed our delivery on time.
8. Our fine manufacturing management and professionals make sure we
can provide you with more competitive high cost-performance product.
A.The blanks of inserts are divided into the following 2 categories:
(1)insert blank with holes
(2)insert blank without holes
B.The inserts blanks are indicated with the following destinations:
(1)The code for indexable inserts blanks with holes consists of type,basic parameter and chipbreakers.
a | b | c | d | e | |
example | 3 | 16 | 03 | c | z |
a:Type
Code | shape |
M | Rhombus85° |
C | Rhombus80° |
3 | Equilateral triangle |
T3 | Convex triangle |
4 | Square |
5 | Equilateral pentahedronb |
b:Inscribed circle diameter
Code | mm Dia mm |
10 | 10 |
13 | 13 |
16 | 16 |
19 | 19 |
25 | 25 |
c:Edge radius
Code | Radius r |
03 | 0.3 |
05 | 0.5 |
10 | 1.0 |
15 | 1.5 |
20 | 2.0 |
d:Chipbreakers
Code |
A |
B |
C |
D |
e:Feeding direction
z | Left |
Right |
(2)The code for indexable inserts blanks without holes consists of type and basic parameter
a | b | c | d | e |
x | 4 | 16 | 05 | 11 |
a:Product type
Code | Product type |
x | blanks |
G | Grounded inserts |
b:type
Code | Shape |
O | Round |
1 | Rectangular |
3 | Equilateral triangle |
T3 | Convex triangle |
4 | Square |
5 | Equilateral pentahedron |
c:inscribed circle diameter
Code | Dia mm |
04 | 4 |
07 | 7 |
10 | 10 |
13 | 13 |
16 | 16 |
19 | 19 |
25 | 25 |
d:edge radius
Code | Radius r |
03 | 0.3 |
05 | 0.5 |
10 | 10 |
15 | 15 |
20 | 20 |
e:Clearance angle
Code | α° |
0 | 0° |
8 | 8° |
11 | 11° |
(3)the thickness of indexable inserts blanks
The thickness of insert blanks with holes as per Table 1
Type | inscribed circle diameter mm IC mm | ||||
10 | 13 | 16 | 19 | 25 | |
Thickness of inserts mm | |||||
Equilateral triangle | 4.5 | 5.5 | 7.0 | 8.5 | - |
Convex triangle | 3.5 | 4.5 | 5.5 | 7.0 | 8.5 |
Square | 3.5 | 4.5 | 5.5 | 7.0 | - |
rhombus | 3.5 | 4.5 | 5.5 | 7.0 | - |
equilateral pentahedron | - | - | 4.5 | 5.5 | 7.0 |
the thickness of indexable inserts without holes as per Table 2
Type | inscribed circle diameter mm IC mm | |||||
7 | 10 | 13 | 16 | 19 | 25 | |
Thickness of inserts mm | ||||||
Equilateral triangle | 3.0 | 3.8 | 4.8 | 5.8 | 7.3 | - |
Square | - | 3.5 | 4.8 | 4.8 | 5.8 | 7.3 |
(4)The diameter of inner holes of indexable blanks as per Table 3
inscribed circle diameter IC mm | 10 | 13 | 16 | 19 | 26 |
Dia. of inner hole mm | 4.2 | 5.2 | 6.2 | 7.2 | 8.2 |
C Code key for ground milling inserts
The code for ground milling inserts consists of the code for type,code for milling inserts(incuding code
for the clearance angle of the cutting edge) and the ic code.
when necessary ,Z or Y is addded to represent left hand or right hand inserts.
example:
3 x H 10 z
3:Code for equilateral triangle
x:Code for milling inserts
H:Code for the clearance angle
10:IC 10mm
z:Left hand insert.
The surface of the grounded inserts shall be 1.25 microns minimum.
The tolerance of the inner hole (fixation hole)of the blanks is +/-0.13mm
The tolerance of the clearnace angle is <=1°
A concave of 0.1mm is allowed on the bosom of the insert blank.
The chip on the cutting edge should be no more than 0.2mm and 0.3mm is allowed in the other places.
No lump material should stick to the cutting edge of the blanks and a light adhesion is allowed in other places.
Chengdu Santon cemented carbide Co.,Ltd is a professional private company,which consists of
producing,selling, and developing of non ferrous metal materials such as cemented carbide
and tungsten and molybdenum products. Santon has a crowd of professional and
experienced personnel , advanced production equipments and quality monitoring
methods.By employing the latest modern technology,Santon can satisfy customers'
demands of high cost-performance cemented carbide and tungsten&molybdenum
products.
Santon has strong independent developing ,designing and producing capabilities.Compare with
the other companies in the same field in China,Santon is the first company which has been given the
certificate of Qualified Management System ISO9001 by UKAS Attestation Company.
Santon is able to provide high technical and high quality before and after sale
services. There are various high performance cemented carbide products under the
brand 'Santon' ,which includes special inserts ,brazed tips ,cutting tools; also non-standard cemented
carbide materials and components which can be designed according to customers'
requirements. We have earned high reputation from customers both at home and
aboard by using our good pristige,fine quality and enthusiastic service.
Santon holds the spirit of 'standing high and aim fair , marking unremitting efforts' and the quality
policy of 'to live on quality , to lead the technology , to improve continually, to satisfy the customers'.
On the other hand, we try hard to create value for society , to increase value for clients and to realize
value for staff . By using diligence and wisdom , we are promoting sustainable development of our
enterprise in order to create a magnificant future.
Our Company has established complete QA system; we can provide not only all kinds of high
quality standard cemented carbide products such as machine-clamped inserts,brazing inserts and high
accuracy coated inserts for clients who are engaged in machining of ferrous metals ,non-ferrous metals
and non-metals ; but also various non-standard cutting tools and hard wearing parts according to
customers' requirement . We can produce not only extensive used cemented carbide materials like P
type,M type and k type,but also new types to satisfy users special needs.
Welcome to use 'Santon' brand products
Welcome to distribute or sell 'Santon' brand products on commision basis.
Welcome to contact us.
1. How long have your company been in this field?
We devoted in manufacturing and R&D of tungsten carbide insert and
other mechanical parts for more than 7 years.
2. Can I investigate the factory on site?
Yes,of course.It's our honour to service for you all the time.
3. How can I pay for my order?
We recommend L/C or T/T,other payment ways are also available.
4. Can I get samples on trial?
Yes,trial order for checking is available.
5. Can we get a discount if the quantity is big enough?
Of course,your large enough order can get best price .
