Product Details
Place of Origin: | Sichuan, China | Brand Name: | Santon | Model Number: | ST-12038 |
Alloy Specification: | WC+Co | Particle: | 1.6-2.4 μm |
Product Description
geological drilling tungsten carbide Inserts with competitive prices
Carbide drag-bit inserts come in various sizes & grades, the common types are always in stock, we can recommend grade for different applications, we can also manufacture the products according to clients' drawings or samples.
Consider the following necessary information when requesting a quotation or placing
an order for your specific application:
1. Physical dimensions, and related tolerance ( if you have)
2. Grade, or chemical composition (WC: Wt% + Co: Wt% + Others : Wt%) , and properties
(Hardness, Density, coercive force, and WC grain size), and associated tolerances, etc.
3. Operation condition and special requirement.
4. Surface condition: sintered blank, fine grinding.
5. Quantity needed.
Only in this way, we can judge and quote exactly on time.
Advantage:
1. High toughness and wear resistance
2. High weldability.
3. Made with Virgin Raw Materials.
4. All products go through in-process and final inspection.
5. Dimensionally accurate, durable and reliable performance
6. Excellent quality and competitive price
Grade | Density (g/cm³) | Hardness (HRA) | T.R.S (MPa) | Application Recommended |
YG4C | 15.1 | 96 | 1800 | Mainly used as small buttons for percussion bits and as the inserts of rotary prospecting bits to cut soft, medium-hard formations. |
YG6 | 14.9 | 94 | 2100 | Mainly used as the buttons of small and medium-sized percussion bits and as the inserts of rotary prospecting bits to cut soft, medium-hard formations. |
YG8 | 14.70 | 92 | 2400 | Mainly used as the buttons of small and medium-sized percussion bits , and as the inserts of rotary prospecting bits to cut soft, medium-hard formations. |
YG8C | 14.70 | 91.7 | 2450 | Mainly used as the buttons of small and medium-sized percussion bits and as the inserts of rotary prospecting bits to cut soft, medium-hard formations. |
YG9C | 14.6 | 91.5 | 2450 | Mainly used as the inserts and buttons for rotary-percussive bits, coal-cutting bits and tricone bits to cut medium-hard and hard formations. |
YG10C | 14.4 | 89.5 | 2550 | Suitable for rock bits of percussion rotary rock drill and buttons, drilling hard and super hard rock. |
YG11C | 14.4 | 88.5 | 2600 | Chiefly for the inserts and buttons of heavy rock drill bits and rotary-percussive bits, coal-cutting bits and tricone bits to cut medium-hard and hard formations. |
YG13C | 14.2 | 87.0 | 2650 | Mainly used as the inserts and buttons of tricone bits rotary-percussive bits and heavy rock drill bits to cut medium-hard and hard formations. |
YG15C | 14.00 | 85.0 | 2700 | It is stronger, and is mainly used as the inserts and buttons of rotary-percussive bits, heavy rock drill bits to cut hard and very hard formations. |
Drawing
