Good Quality Steel Materail hq nq bq Drill Rod for Sale
US$ 100 - 120
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
Ruilong, RL(Ruilong)
Model Number:
RL, AQ,BQ,NQ,HQ,PQ,NRQ,HRQ NW HW BW AW PW
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao/Tianjin/Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2017 Hot- Sale Water Well Drill RodUS$ 100 - 120MOQ: 100 Pieces -
bq nq hq pq Rock Drilling Rod ClampUS$ 100 - 120MOQ: 100 Pieces
-
BQ NQ HQ PQ AW BW Drill Rod, Drill PipeUS$ 100 - 120MOQ: 100 Pieces
-
DTH Drill Rod /Drill Pipe For Water Well DrillingUS$ 100 - 120MOQ: 100 Pieces
-
BQ NQ HQ PQ AW BW Drill Rod, Drill PipeUS$ 100 - 120MOQ: 100 Pieces
Place of Origin
Shandong, China
Brand Name
Ruilong, RL(Ruilong)
Model Number
RL, AQ,BQ,NQ,HQ,PQ,NRQ,HRQ NW HW BW AW PW
Type
Other, Drill Bit, Drill Pipe
Machine Type
Other, Drilling Tool, Drilling Tool
Certification
API
Material
Carbon Steel
Processing Type
Forging
Use
Other, Well Drilling, Ore Mining
Product Description
drill rod for sale
| Q series Rod parameter-geological steel pipe-entire length thermal treatment, NQ lathe with former cutters | |||||
| Spec. | Unit | BQB | NQB | HQB | PQB |
| OD/ID | mm | 55.6/46 | 71/60 | 89/77.8 | 114.3/101.6 |
| Thickness | mm | 4.8 | 5.5 | 5.6 | 6.35 |
| Length | m | 1.5 or 3 | 1.5 or 3 | 1.5 or 3 | 1.5 or 3 |
| Weight | kg/m | 6.01 | 8.8 | 11.51 | 17.3 |
| thread length | mm | 44.45 | 44.45 | 44.45 | 63.5 |
| thread pitch | thread/inch | 3 | 3 | 3 | 2.5 |
| box thread tooth height | mm | 0.76 | 0.76 | 0.76 | 1.17 |
| pin thread tooth height | mm | 0.88 | 0.88 | 0.88 | 1.27 |
| thread tooth angle | . | 29 | 29 | 29 | 29 |
| tensile resistance(A series) | kn | 400 | 530 | 510 | 565 |
| tensile resistance(B series) | kn | 450 | 615 | 625 | 660 |
| bore depth | m | 1200 | 1000 | 900 | 800 |
| QR series Rod parameter-geological steel pipe-entire length thermal treatment, NQ lathe with former cutters | |||||
| Spec. | Unit | BRQ | NRQ | HRQ | PRQ |
| OD/ID | mm | 55.6/46 | 69.9/60.3 | 88.9/77.8 | 114.3/101.6 |
| Length | m | 1.5 or 3 | 1.5 or 3 | 1.5 or 3 | 1.5 or 3 |
| Weight | kg/m | 6.01 | 8.8 | 11.51 | 17.3 |
| thread length | mm | 42 | 42 | 41.91 | 63.5 |
| thread pitch | thread/inch | 3 | 3 | 3 | 2.5 |
| box thread tooth height | mm | 0.76 | 0.76 | 0.76 | 1.17 |
| pin thread tooth height | mm | 0.88 | 0.88 | 0.88 | 1.27 |
| thread tooth negative angle | . | 5 | 5 | 5 | 5 |
| tensile resistance(A) | kn | 450 | 525 | 545 | 565 |
| tensile resistance(B) | kn | 530 | 625.5 | 602 | 660 |
| bore depth | m | |
|||
