1/3'' SONY Super HAD CCD 20X20mm 600TVL Super Mini Camera for CCTV

Shenzhen Correa Electronic Co., Ltd.
1/3'' SONY Super HAD CCD 20X20mm 600TVL Super Mini Camera for CCTV thumbnail-1
1/3'' SONY Super HAD CCD 20X20mm 600TVL Super Mini Camera for CCTV photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
correa
Model Number:
CS3120CH
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name correa
Model Number CS3120CH
Type Analog Camera
Style Mini Camera
Sensor CCD
Technology Pan / Tilt / Zoom
Special Features Waterproof / Weatherproof

Specifications

Correa SONY Super HAD CCD 20X20mm 600TVL Super Mini Camera
1. Tiny size: 20x20mm
2. High resolution

Specifications



Correa SONY Super HAD CCD 20X20mm 600TVL Super Mini Camera
1. Tiny size: 20x20mm
2. High resolution



* 1/3" Sony Super HAD CCD II

*  High-Resolution of 600 TVL
* Extream Clear Cutting Edge Picture
* Unmatched Low-Light Sensitivity of 0.05 Lux / Faceplate
* Ultra Compact Size of 20(W) x 20(H) mm
* Fixed Iris Board , Pinhole Lens
* Attractive Design with Non-Reflective Coating



Low Current Frequency , only 50mA, solve the hot problem ,nice back light compensation, used for the ATM surveillance or under sharp contrast in lighting conditions.

Model No.
CS3120CH (3.6mm board lens)
Image Device
1/3" Sony Super HAD II Color CCD
Horizontal Resolution
600 TVL
Minimum Illumination
0.05 lux
Number of Pixels
PAL : 752(H) x 582(V), NTSC :768(H) x 492(V)
Scanning System
PAL:625 Lines,50 Field/Sec; NTSC:525 Lines,60 Field/Sec
Sync System
Internal Synchronization
Video output
1Vp-p 75 Oms , Negative
White Balance
Auto
S/N Ratio
More Than 48dB (AGC off)
Gamma Characteristic
0.45
Electronic Shutter
PAL : 1/50~1/100,000 Sec; NTSC :1/60~1/100,000 Sec, auto
Lens
3.6mm MTV lens
Power Consumption
DC 5-15V, 50mA
Operation Temperature
-10°C ~ + 50°C, RH 95% Max
Storage Temperature
-20°C ~ + 60°C, RH 95% Max
Housing
Black
Dimension
20x20mm,2-board
