Wireless Video FPV 5.8GHz Transmitter and Receiver

Wireless Video FPV 5.8GHz Transmitter and Receiver thumbnail-1
Wireless Video FPV 5.8GHz Transmitter and Receiver thumbnail-2
Wireless Video FPV 5.8GHz Transmitter and Receiver photo-1
Wireless Video FPV 5.8GHz Transmitter and Receiver photo-2
US$ 8 - 10 MOQ: 1 Piece
Key Specifications
Get Latest Price
Type:
Other, FPV Video Transmitter
Power:
Battery
Material:
Plastic
Contact Supplier Request Quote Chat Now
Shenzhen Correa Electronic Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Other, FPV Video Transmitter
Power Battery
Material Plastic
Plastic Type ABS
Scale Other, 1:1
Radio Control Style RC Hobby
Place of Origin Guangdong, China
Brand Name Correa
Model Number TS5823L
Product Description



Wireless Video FPV 5.8GHz Transmitter and Receiver

With super tiny size and ultra lightweight, this TS5823 FPV audio video transmitter is suitable for small multirotors and super light air vehicles. It is also very suitable for DJI Phantom series.  As smaller than the thumb, the weight is 7.3 gram ONLY.

Specifications:
Modulate: Wideband FM Modulate
Video Format : NTSC/PAL
Output Impedance:50 Ohm
Output Power : 23-24dBm
Channel:40CH
Operating Voltage: 7V-24V
Supply Current : 190mA
Operating Temperature: -10~85°C
Video Band Width : 0~8.0 MHz
Audio Carrier Frequency : 6.5 MHz
Video Input Level: 0.8~1.2 Vp-p
Video Input Impedance : 75 Ohm
Audio Input Level : 0.5~2.0 Vp-p
Audio Input Impedance : 10K Ohm
Connector: SMA Female(outer hole),RP-SMA Female(outer needle)
Antenna Connector: SMA Male(Inner needle),RP-SMA Male(Inner hole)
Dimension: 40mm x 23mm x 8mm
Weight: 7.3g

Packaging & Shipping

 Wireless Video FPV 5.8GHz Transmitter and Receiver

Ready in stock and ship within 1 working day after payment received.

Our Services

* Enquiries will be replied within 1 working day.



* Fast samples arrangement and on time production.



* We accept payment methods include T/T, PayPal, Western Union,etc.



* All the products are aged and tested before shipment.



* Tracking information provided promptly.

Company Information

Correa, is  a professional manufacturer & exporter specialized in FPV Equipments including FPV Cameras, Wireless Tx Rx (5.8GHz, 1.2-1.3 GHz, 900MHz, 2.4GHz), FPV Monitors, FPV Antennas and RC Hobby Parts, etc.



With more than 8 years experience we are able to supply high quality FPV Equipments. Welcome to deal business with us!
